PLANAR 808/1 Vector Network Analyzer (4ports,8GHz)

PLANAR 808/1 Vector Network Analyzer (4ports,8GHz) 1

PLANAR 808/1 Vector Network Analyzer (4ports,8GHz) 2

PLANAR 808/1 Vector Network Analyzer (4ports,8GHz) 3

Model:	PLANAR 808/1
Brand:	Copper Mountain Technologies
Origin:	Made In Russian Federation
Category:	Electronics & Electricity / Electronic Instrument / Electronic Measurment Apparatus
Label:	PLANAR 808/1 , PLANAR , CMT
Price:	US $35000 / pc
Min. Order:	1 pc

Inquire Now Add to Basket

Member Information

TS RF Instruments Co., Ltd.

Free MemberTaiwan, China

Live Chat:

Last Online:27 Aug, 2022

Product Description

http://www.ts-corp.com.tw

Planar 808/1 is a four-port VNA that allows the user to test up to 16 S-parameters (S11 through S44) at once. With two independent signal sources, 808/1 is ideal for mixer and converter measurements.

The interface is implemented in a PC-driven format: it connects to any Windows-capable machine via USB and delivers accurate testing and measurement through a platform that can keep up with constant advancements as well as be remotely accessed.

Frequency range: 100 kHz to 8 GHz
Measured parameters: S11 to S44
Power output range: -60 dBm to +10 dBm
Up to 500,001 measurement points
Measurement time per point: 100 µs
Frequency setting resolution: 1 Hz

Product Image

Img 1

Img 2

Img 3

Img 4

Img 5
