| Model: | ECS-60 |
|---|---|
| Brand: | JSYY |
| Origin: | Made In China |
| Category: | Industrial Supplies / Environment Protection Facilities / Other Environment Protection Facilities |
| Label: | Eddy Current Separat , laboratory separator , nonferrous metal |
| Price: |
¥195000
/ set
|
| Min. Order: | 1 set |
| Live Chat: |  | Last Online:29 Apr, 2024 |
Structural characteristics:
Concentric rotor eddy current separator swirl rotor and outer cylinder are concentric。The device has the characteristics of larger separation region、stronger separation power ，etc.
A variety of models and structures are provided for customers to choose. Eddy current separation equipment can be used to remove aluminum and non-ferrous metals from municipal solid waste, glass cullet, electronic scrap, etc.
Field of application
Waste plastic trash separation
PET bottle chip removing aluminum separation
Three rubber aluminum removal
Waste glass separation
Renewable resources
Technical Parameter:
| Model | Belt Width | Handling Capacity | Motor Power | Motor Appearance Measurementpower | Weight | ||
| mm | m3/h | kw | L | W | H | kg | |
| ECS-60 |
600 |
5-8 | 5.5/1.1 | 3300 | 1500 | 1200 | 1200 |
| ECS-80 | 800 | 6-10 | 7.5/1.5 | 3300 | 1700 | 1200 | 1400 |
| ECS-120 | 1200 | 8-12 | 11/3.0 | 3300 | 2000 | 1200 | 1800 |
| ECS-150 | 1500 | 10-15 | 11/3.0 | 3300 | 2300 | 1200 | 2200 |
| Price Terms: | FOB Dalian |
|---|---|
| Payment Terms: | 30% paid for deposit by T/T and the balance should be paid upon the copy of B/L. |
| Packing: | standard packing |
| Lead Time: | within 50 days after reveive the deosit |
