| Model: | EU Series |
|---|---|
| Brand: | DEMIELE AIR |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Air Compressor |
| Label: | air compressor |
| Price: |
US $500
/ pc
|
| Min. Order: | 3 pc |
| Last Online:30 May, 2014 |
Features:
Low noise, high temperature resistance;
The whole compressor for a complete unit;
Small and exquisite, compact structure, smooth operation, the operation simple and easy to understand.
| Model |
free air delivery/Discharge air pressure(m³min/Mpa) |
Power(KW/HP) |
Length(mm) |
Width(mm) |
Height(mm) |
Weight(kg) |
Vent diameter |
| EU-8A | 1.1/0.7 1.0/0.8 0.9/1.0 0.7/1.3 | 7.5/10 | 880 | 620 | 780 | 220 | 3/4″ |
|
EU-8A (with tank) |
1.1/0.7 1.0/0.8 0.9/1.0 0.7/1.3 | 7.5/10 | 1253 | 662 | 1530 | 320 | 3/4″ |
| EU-11A | 1.8/0.7 1.7/0.8 1.5/1.0 1.2/1.3 | 11/15 | 900 | 750 | 885 | 240 | 3/4″ |
|
EU-11A (with tank) |
1.8/0.7 1.7/0.8 1.5/1.0 1.2/1.3 | 11/15 | 1253 | 750 | 1635 | 340 | 3/4″ |
| EU-15A | 2.5/0.7 2.3/0.8 2.0/1.0 1.7/1.3 | 15/20 | 900 | 750 | 885 | 260 | 3/4″ |
|
EU-15A (with tank) |
2.5/0.7 2.3/0.8 2.0/1.0 1.7/1.3 | 15/20 | 1253 | 750 | 1635 | 360 | 3/4″ |
| EU-22XA | 3.7/0.7 3.5/0.8 3.1/1.0 2.6/1.3 | 22/30 | 1290 | 900 | 1190 | 600 | 1″ |
| EU-37A | 6.5/0.7 6.2/0.8 5.6/1.0 4.5/1.3 | 37/50 | 1520 | 955 | 1365 | 850 | 1-1/4″ |
| EU-45A | 8.0/0.7 7.5/0.8 6.8/1.0 5.5/1.3 | 45/60 | 1520 | 955 | 1365 | 850 | 1-1/4″ |
