Need more wireless connectivity for your home or office wireless network infrastructure? This antenna will transmit your data at a relentlessly fast rate at uncompromised signal strength and integrity, giving your network and network users more versatility and functionality by transmitting signals to extra, hard-to-reach places. The antenna is designed by the top-notch, finest engineers and manufactured with the best quality materials to the highest specifications to ensure reliability, dependability, and maximum operational efficiency under extreme stress situations and during high usage intensive operations, delivering clutch performance to transmit mission critical data when you most need it.

Features

Frequency: 2400-2485MHz

VSWR: <1.5

Gain: 24dBi

Suitable Temperature: -40°C ~ 60°C

Front to Back Ratio: >30dB

Horizontal Beam Width: 10°

Vertical Beam Width: 14°

Polarization Type: Vertical

Rated Power: 150w

Input Impedance: 50Ohm

Lightning Protection: Direct Ground

Connector Type: N Female

Dimensions: 600 x 900 mm

Rated Wind Velocity: 60m/s

Wire Cable: 30CM

Mount: 5 Inches Length/3 Inches Wide

Rod: 12 Inches Length/3.25 Inches Wide
