CWZ Marine small sized axial fan,exhaust fan

Model:CWZ
Brand:YAOSEN MARINE
Origin:Made In China
Category:Industrial Supplies / Machinery / Draught Fan
Label:Marine blower , small sized fan , axial fan
Price: US $160 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Yaosen Marine Industrial Equipment Co.,Ltd.

Free MemberShan Dong - China
Live Chat:
Last Online:14 Apr, 2020

Product Description

CWZ Marine small sized axial fan,exhaust blower

 Marine fan,marine ventilator,marine blower,axial fan,axial flow fan,axial blower,axial ventilation fan,axial ventilator,exhaust fan,ventilating fan,ventilated fan,supply fan,draft fan,ship fan,vessel fan,ship blower,ship ventilator,vessel blower,vessel ventilator

CWZ Series Marine or Navy Small-sized Axial Fans

1General

CWZ series marine or navy small-sized axial fans are suitable for, ventilation of kitchen ,lavatory, bulkhead ,the public places ,the meeting room etc, in the naval and merchant shops. They are also applicable in other places that suit.

2Features

The fans are designed according to arbiter votes flow method. We choose the most reasonable votes flow coefficient on the vanes of the fans, specification ,distribute every sectional characteristic speed & length of the vanes ,the fans have low-noise, small size, light-weight ,stable performance , etc.

In the course of designing & manufacturing, we had thought fully of the marine special conditions, the impellers are strictly made by dynamic balance adjustment & over speed test. Therefore, the fans also have the features of good-anticorrosion, anti-swing, vibration  resistance ,shock resistance, stable running and safety reliable.

The fans can be used with 380V/220V.50Hz or 440V/220V,60Hz.

3Structure

The fans can be made into two structure types, type Ⅰ(tube type),type Ⅱ(porthole type):

Ⅰtype-tube type for ventilation of short tubes or fixed on the bulkhead.

Ⅱtypefixed on porthole .It can be fixed on the porthole or the bulkhead. Since it's waterproof it can be easily opened or closed, keep rain or sea water out.

Impeller is made of cast aluminum alloy, casing is welded of steel sheet.

4Model explanation

1The hard particulate matter in the combustible and explosive gas mixture is not allowed to be more than 150mg/ m3,and its maximum diameter cannot exceed to 2 mm.

2On the duct intake side, provide a protective brass wire nets to ensure the prevention of foreign matter and electrostatic sparks from invasion, so as to insure the explosion-proof fan operating safely.

3When a power cable is inserted in the terminal box and fixed there ,the terminal box itself and its approaching device must be sealed tightly with the cable, and no permeation of rain water into the terminal box is allowable.

4Be sure to earth the cable, especially the flameproof motor.

5Explosion-proof fan installation should be carried out with much care in connecting with the duct so as not to allow any casing distortion to take place owing to forceful tightening .Furthermore ,it is not allowed to add the weight of pipes to fans by forceful.

6The motor power wied by fans refers to mechanical losses and its own safe coefficient under given working conditions .Be sure to adjust the air rate and strictly control motor's electrical current .It is forbidden to exceed motor's electrical correct rating.

7The cable entry thread of the flameproof motors are shown in table.

8Our products can be exchanged, returned and repaired if found its quality unsatisfactory within 18 months from the date of exfactory.



 Marine fan,marine ventilator,marine blower,axial fan,axial flow fan,axial blower,axial ventilation fan,axial ventilator,exhaust fan,ventilating fan,ventilated fan,supply fan,draft fan,ship fan,vessel fan,ship blower,ship ventilator,vessel blower,vessel ventilator


Price Terms:EXW
Payment Terms:TT/LC
Lead Time:15 DAYS
Standards Certificate:CCS/ABS/RINA/RS/GL/NK/KR/DNV/RINA/VR/LR

Product Image

CWZ Marine small sized axial fan,exhaust fan 1
Img 1
CWZ Marine small sized axial fan,exhaust fan 2
Img 2
CWZ Marine small sized axial fan,exhaust fan 3
Img 3
CWZ Marine small sized axial fan,exhaust fan 4
Img 4
CWZ Marine small sized axial fan,exhaust fan 5
Img 5
