| Model: | QLM-2408-8000B |
|---|---|
| Brand: | Clairvoyance |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Telecommunication & Broadcasting / Wireless Equipment |
| Label: | Wireless Video , Wireless microwave , Wireless video surve |
| Price: |
US $401
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:06 Jun, 2016 |
Wireless microwave transmission analog camera output video 4 km waterproof transmitter
Emitter parameter
Model QLM-2408-8000B
CBM 250mm (a) * 160mm (b) * 70mm (h)
8 adjustable channel
Voltage / current 220V-12V / 2000mA
Environment -20 ℃ - +60 ℃
Frequency 0.9G - 1.28G
Power 8000mW 43dBM
Accessible transport 2000M-5000M
Video Output 1V-p
Not waterproof receiver parameters
Volume 135 * 80 * 21mm
Environment -20 ℃ - +60 ℃
Voltage / Current 9-12V/250mA
Frequency 09G-1.3G
Sensitivity-85Dbm
Open extended transmission distance and the use of environmental scope statement
Standard 13DB antenna on 2000 m -4000 m; another antenna with the following prices: 9DB Biography 3500 m to the suction cup antenna; 20DB pass pass 5000 meters parabolic antenna; for wireless remote transmission image
Kit
A waterproof transmitter 8 channels
8-channel receiver is a not waterproof
Reception 12V 500 mA power which a
13dB Yagi directional antenna 2
Receive Take a dedicated connection
Manual a copy
+2 + Receiver transmitter antenna support large shipments with a total weight: 4 kg, shipped outside the packing volume 310 * 210 * 80mm as converted into 20DB parabolic antenna 2 total weight of 7 kg
