Heavy duty rack:

Description on Subordinate Heavy-Duty shelving rack

1. This kind of rack is the articulated structure with beams and upright slices

2. The beam can be freely adjusted the distance of 75mm for the layer height

3. Reasonable structure, strong and durable; and needn’t bolt to connection

4. Load capacity between 300kg to 800kg, high safety factor

5. The sizes and colors can be set with the customer needs.

6. Widely used in large and medium enterprises’ warehouse storage.

7. Size(L*W*H):

 L(1500-3000mm)

 W(500-12000mm)

 H(3000-6000mm)

Structural features

1. Subordinate heavy-Duty shelving rack are made by the cold-rolled steel. The uprights are the steel,Ω shaped, 80(90)×60(70), punched rhombic holes, and beams are the embrace-welded, 80×50-100×50-120×50-140×50, jointed by the hooks.

2. Subordinate heavy-Duty shelf usually uses the tray instead of steel plate so that it's more convenient to use the forklift. The load capacity is between 1ton-5tons, and the surface is the electrostatic spraying, which has the strong power such as water-proof,rust-proof, anti-corrosion, and high safety, plug-in type and non the screw and welding, simple assembly. It can fully make use of the space and improve the storage capacity, and can be designed according to customers' requirement.

Designing by

1. To carry out packaging unit that make the cargo packing and weight characteristics group to determine the tray type, size, and single tray load, stack height (generally single-tray's cargo weight less than 2000kg);

2. Determine the span of the unit shelf, depth, spacing, according to the effective height of warehouse roof edge and the maximum fork height to decide the shelf height. Unit shelf span is generally less than 4m, depth within 1.5m, and the low, high storage shelf height is generally less than 12m, ultra-high storage shelf height is generally less than 30m (This kind of warehouses are equal the automated).

Using Scope

Widely used in manufacturing, third-party logistics and distribution centers field, suitable for kinds of items and varieties goods. In addition, to improve space utilization, alley width can be reduced; with a special push truck, storage space could be made the vertical, so it has become the narrow-aisle rack.
