| Model: | SLA-610 |
|---|---|
| Brand: | Shell_Conning |
| Origin: | Made In China |
| Category: | Industrial Supplies / Packaging Related Machine |
| Label: | Labeling Machine , Packaging Machinery , Self Adhesive Label |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:22 Nov, 2013 |
Main technical parameters:
|
Model No. |
SLA-610 Horizontal Round Bottle Labeling Machine |
|
Bottle Type & Size |
Diameter: Φ10—22mm Φ18-30mm |
|
Labeling Speed |
200-300 /ppm ( Related to the Bottle size/ Label type) |
|
Stop Labeling Precision |
±0.3mm |
|
Labeling Machine Precision |
±1.0 mm |
|
Use environment Temperature |
5-45℃ |
|
Use environment humidity |
15-90% (non-condensing ) |
|
Width of Conveyer belt |
91mm (Can according to customer material’s features make the Width and Length of the Conveyer Belt ) |
|
Machine Outer Size (mm) |
(L):2010mm*(W)720mm*(H)1600mm |
Main Application :
The machine is widely application for :
Pharmaceutical& Medical industry such as ampoule ,penicillin bottle, oral liquid bottle and so on ,
Stationery products such as Pen, Glue pen and so on
Daily cosmetic industry such as lipstick ,Lip balm ,and small cylindrical material labeling requirements
Product Details:
Main Function :
Automatic Tidy bottles turntable
A: Adopt the star wheel feeding to improve the efficiency of labeling machine
B: Rotation bottle belt rotary mechanism
Effectively solved the problem of the small bottles can not easy to stick
C: Receiving bottle part
Realize high –speed and accurately put bottles into bottle holder of the labeling well
Synchronization function:
a :Can be equipped with printing equipment or hot-iron printer to realize synchronous printing production date and related information.
b: Flexible connection automatic production line and single use
The main performances and features:
1 Horizontal roller conveyor belt feeding effectively solves the small bottle is not convenient for vertical feeding problems. Labeler to bottle as a calibration point, to ensure the accuracy of labeling
2, Can configurable model into the bottle support device, to realize high speed accurately put the bottle into the bottle labeling after supporting.
3, The bottle support multiple detection, automatic nursery rate greatly improved.
4, Through the bottle tray conveyor belt by manual support, or linkage brake tray machine feeding.
5, In the surge bin and labeling action synchronization with: less support, labeling speed will reduce; when the lack of bottles, bottle support automatic stop waiting.
6,Optional hot printing machine, complete synchronization code marking and labeling the thermal transfer printer or printer.
7, With equipment running status and alarm information will be reflected in the system.
Packaging & Delivery
|
Packaging Details: |
Packed in wooden case with well-supported materials wrapped |
|
Delivery Detail: |
Delivery within 20 working days after receipt of deposit |
