| Model: | KD3636 |
|---|---|
| Brand: | KD |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Engraving & Etching Machine |
| Label: | mental cnc router , marble cnc machine , granite engraving |
| Price: |
US $3400
/ SET
|
| Min. Order: | 1 SET |
| Live Chat: | Last Online:23 Oct, 2016 |
3636 marble granite stone mental cnc router
|
Model |
KD3636 (360mmx360mm) |
|
Spindle motor |
1.5KW, 800w inverter-driven spindle motor cooled by water |
|
Engraving speed |
6000mm max12000mm / min |
|
Rotation speed of spindle |
24000 RPM |
|
Engraving tools |
3. 175mm 4mm 6mm |
|
Format dictates |
G-code |
|
transmission |
Two-nut rolling ball screws from Germany for x,y,z axis square linear guide way |
|
Resolution |
0. 01mm |
|
High Speed |
synchronization of processing curves and straight lines can be up to speed of 12m / min |
|
Massive Memory Capacity |
Standard Capacity of 128MB, Store 20 files simultaneously makes processing at ease. |
|
Quick Data Transmission |
USB interface, work without computer, not occupying computer resources |
|
Multi-Compatibility |
Be compatible with popular CAD / CAM |
|
Software |
type 3 / Artcam / Casmate / Proe / UG / Artgrave etc. |
|
Packing dimension |
1m*1m*1.3m 135kgs
|
Application
Marble,stone,granite,engraving,Aluminum,copper,iron
Sign making,department nameplate,chest badge,architectural model
ABC plate,acrylic cutting,jade,metal,glass,wood and so on.
Guarantee & after sales service
1. 1 year guarantee.
2. 24 hours technical support by e-mail or calling.
3. Use the English Manual and CD Video to know the operating and maintaining.
Features
1.Integral cast-iron frame,embedded square linear,much more stable and solid structure.
2.Rolling ball screw from Germany, two nut eliminating clearance, advanced fixing mode of three bearings.
3.Configured 1.5kw inverter-driven spindle motor cooled by water
4.Control system: NC studio control system or DSP control system.
5.Easy operation, rigid, durable, reliable performance
| Payment Terms: | T/T/Western union/paypal |
|---|---|
