|Origin:||Made In China|
|Category:||Industrial Supplies / Electrical & Electronic Product Equipment|
|Label:||cutting machine , Tube cutting machine , PVC cutting machine|
|Min. Order:||1 SET|
CNC pvc tube Cutting Machine / Automatic Multi-function cutting machine
Applications : pvc cutting machine, tube cutting machine, automatic cutting machine
use for cutting various kinds of materials, for example :
Velcro tape, rubber band, rubber tube, pvc tube, heat shrink tube,silicone sleeving, wires, foam tube, fiberglass, fabric, ribbon hot cut etc...
Models for option : YS-100, YS-120,YS-160,YS-160W,YS-120WH, YS-200W, YS-250W, YS-300W
If you are interested in our machine pls tell us your cutting materials and cutting materials size then we will know which models is the most suitable one for you.
1. Electric Load : AC220V/50Hz & AC110V/60Hz
2. Electric Power : 250W
3. Cutting Length : 0-.1-9999.9mm
4. Cutting Width : 0-100mm
5. Cutting Diameter : 0-12mm
6. Cutting Speed : 100-120cuts/min(depend on the cutting length)
7. Net Weight : 28kg
8. Dimension : L360*W300*H350MM
1. High speed: It can cut 100~120 cut per minute. (50mm long)
2. Tolerance: +/- 0.5% of cutting length
3. Cutting type: Cutting is neat due to using a cold cutter which is durable.
4. Automatic operation: It works automatically only by setting length and quantity
5. Automatic stopper: It stops automatically if materials run out during operation
6. Memory: Set-length, set quantity & set speed will not be erased even if power off & on
7. Application: Belt loop, soft tube, string, plastic zipper, elastic band, small webbing, etc.
8. Heavy duty, high speed, high accuracy, designed for cutting non-adhesive materials.
