| Model: | GW series |
|---|---|
| Brand: | kemercn at hotmail dot com |
| Origin: | Made In China |
| Category: | Transportation / Logistics / Lifting Systems |
| Label: | hydraulic winch , hoisting winch , marine winch |
| Price: |
US $1000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:25 Jul, 2022 |
hydraulic winch, hoisting winch, wireline winch, cargo winch, drilling rig winch, crane winch, marine winch, dredger winch, hydraulic winches, compact winch, free fall hydraulic winch
GW series hydraulic winches (hydraulic winch, hoisting winch, wireline winch, drilling rig winch, crane winch, dredger winch) are widely used in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery.
Features:
1. One-or two-stage planetary gearboxes, smooth operation and reasonable structure.
2. Normally closed friction type brake, high braking torque, safe and reliable operating.
3. Small volume, compact structure and high transmission efficiency.
4. Radial piston hydraulic motor with long life operating.
5. Mounting frame is available on request.
6. Balance valve, shuttle valve, limit switch and other accessories are also available on request.
For the following specification in table, it is for your reference. We can also manufacture the winch with pull force up to 50,000kgs based on your requirements.
|
Model |
The1st layer |
Diameter of reel bottom (mm) |
Total displacement (ml/r) |
Working pressuresdiff. (Mpa) |
Diameter of rope (mm) |
Capacity of rope (mm) |
|
|
Pull Force (KN) |
RopeSpeed (m/min) |
||||||
|
GW2.5-10-60-10-ZP |
10 |
0-30 |
238 |
575 |
15.0 |
10 |
60 |
|
GW2.5-20-50-12-ZP |
20 |
0-30 |
238 |
1050 |
17.0 |
12 |
50 |
|
GW3-30-65-15-ZP |
30 |
0-35 |
305 |
2125 |
15.9 |
15 |
65 |
|
GW3-40-60-16-ZP |
40 |
0-35 |
305 |
2711.5 |
16.4 |
16 |
60 |
|
GW4-50-70-20-ZP |
50 |
0-40 |
380 |
4365 |
16.3 |
20 |
70 |
|
GW4-60-68-21.5-ZP |
60 |
0-40 |
380 |
5428.5 |
16.0 |
21.5 |
68 |
|
GW5-80-100-24-ZP |
80 |
0-40 |
470 |
9080 |
15.6 |
24 |
100 |
|
GW5-100-90-28-ZP |
100 |
0-40 |
470 |
11039 |
16.0 |
28 |
90 |
|
GW6-120-176-30-ZP |
120 |
0-30 |
600 |
16725 |
17.0 |
30 |
175 |
|
GW6-150-150-34-ZP |
150 |
0-25 |
600 |
16725 |
19.8 |
34 |
150 |
We can also design and manufacture based on your requirements with pull force up to 100 ton.
If you are interested, please contact me:
Contact information:
Contact: Cathy Hsu
Email: kemercn@hotmail.com;sales@bonnyhydraulic.com
Tel/whatsapp: 0086-13486645746
Skype: kemercathy
For the catalogue, please click here.
