| Model: | QW-JR3W-BW |
|---|---|
| Brand: | QW |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Diode & Triode |
| Label: | led with heatsink , 3w white led , led |
| Price: |
US $0.4
/ pc
|
| Min. Order: | 50 pc |
| Last Online:04 Sep, 2013 |
| Product Name | 3w white led |
| Chip brand | Epistar,brigelux,Epileds (Available) |
| Color temperature | 2500-3500K(Warm white ).5500-6500K ( Pure white).7000-8000K (cold white) (2500-25000k are available). |
| High intensity | 200-220Lm |
| Working Voltage | 3.2-3.4V |
| Working current | 700mA |
|
Available angle |
60,90,120 and 140 degree |
|
Available Color |
Warm White/ White/Cold white, Red,Green,Blue,Yellow,RGB,UV and so on |
|
Operating Temperature Range |
-20°C to 80°C |
|
Storage Temperature Range |
-30°C to 100°C |
|
Lifespan |
50,000h |
| Modeal | Chip Material | Emitting Color | Forward voltage (V) | Forward current (mA) | Luminous (Lm) | Viewing angle (Deg) |
| QW-JR3W-DW | InGan | 2500-3500K | 3.0-3.6V | 700mA | 190-210 |
140 |
| QW-JR3W-NW | InGan | 3500-5500K | 3.0-3.6V | 700mA | 200-220 | 140 |
| QW-JR3W-BW | InGan | 5500-7000K | 3.0-3.6V | 700mA | 200-220 | 140 |
| QW-JR3W-CW | InGan | 7000-9000K | 3.0-3.6V | 700mA | 200-220 | 140 |
| QW-JR3W-LW | InGan | 9000-12000K | 3.0-3.6V | 700mA | 200-220 | 140 |
| QW-JR3W-AW | InGan | 12000-15000K | 3.0-3.6V | 700mA | 180-200 | 140 |
| QW-JR3W-EW | InGan | 15000-25000K | 3.0-3.6V | 700mA | 180-200 | 140 |
| QW-JR3W-AR | AIGainp | Red 620-630nm | 2.0-2.4V |
700mA |
80-100 | 140 |
| QW-JR3W-JR | AIGainp | Red 660-670nm | 2.0-2.4V | 700mA | 30-40 | 140 |
| QW-JR3W-DG | InGan | Green 520-530nm | 3.0-3.6V | 700mA | 120-140 | 140 |
| QW-JR3W-DB | InGan | Blue 460-470nm | 3.0-3.6V | 700mA | 30-40 | 140 |
| QW-JR3W-CY | AIGainp | Yellow 590-595nm | 2.0-2.4V | 700mA | 80-100 | 140 |
| QW-JR3W-DP | InGan | Purple 400-405nm | 3.0-3.6V | 700mA | 3-4 | 140 |
