| Model: | MJ6132C |
|---|---|
| Brand: | AUYU |
| Origin: | Made In China |
| Category: | Industrial Supplies / Tools / Woodworking |
| Label: | Panel saw , sliding panel saw , Sliding table saw |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:20 May, 2016 |
|
Model |
MJ6128C |
MJ6132C |
MJ6138C |
|
Max. Cutting Length |
2800mm |
3200mm |
3800mm |
|
Main Saw Blade Diameter |
Φ300mm |
Φ300mm |
Φ300mm |
|
Cutting Thickness Φ300mm |
90mm |
90mm |
90mm |
|
Main Spindle Diameter |
Φ30mm |
Φ30mm |
Φ30mm |
|
Speed of Main Saw Blade |
4000/6000rpm |
4000/6000rpm |
4000/6000rpm |
|
Tilting Saw Blade |
0-45° |
0-45° |
0-45° |
|
Main Motor |
4.0kw |
5.5kw |
5.5kw |
|
Scoring Saw Blade Diameter |
Φ120mm |
Φ120mm |
Φ120mm |
|
Scoring Spindle Diameter |
Φ20mm |
Φ20mm |
Φ20mm |
|
Speed of Scoring Saw Blade |
8000rpm |
8000rpm |
8000rpm |
|
Scoring Motor |
0.75kw |
0.75kw |
0.75kw |
|
Net Weight |
700kg |
760kg |
860kg |
|
Overall Dimensions |
2850x3150x900mm |
3250x3150x900mm |
3850x3150x900mm |
| Payment Terms: | TT, L/C |
|---|---|
