| Model: | M33-M77 |
|---|---|
| Brand: | YB |
| Origin: | Made In China |
| Category: | Industrial Supplies / Rubber & Plastics Machine |
| Label: | 3-30mm plastic rope , plastic rope machine , nylon rope machine |
| Price: |
US $7000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:22 Feb, 2021 |
3-30mm plastic rope machine
Theplastic rope making machineis making strands and ropes together made a new machines.
Suitable for plastic round yarn, flat yarn, monofilament,cotton, hemp, monofilament as raw material to produce rope.
Main features
7. From making rope to taking rope can once completed
8. Inverter driving, meter counter, Setting meters can be automatically stop，use the second start way, automatically cut off power supply if open the door
9. Adjustable twist
10. Stable performance,low consumption, little noise, convenient maintenance
|
Model |
M88 |
M77 |
M66 |
M55 |
M44 |
M33 |
|
Rope Diameter mm |
20 -26 |
18-24 |
14 -22 |
10 -14 |
5 -10 |
3 -6 |
|
Twisted Degree /m |
16-62 |
16-62 |
16-62 |
16-62 |
16-62 |
26-82 |
|
Twisted Orientation |
S or Z |
S or Z |
S or Z |
S or Z |
S or Z |
S or Z |
|
Motor Power KW |
18 |
15 |
11 |
7.5 |
5.5 |
3 |
|
Dimension M |
13.8×2.5×2.1 |
12×2.3×2.1 |
9.2×2.2×2.1 |
9.2×2.2×2.1 |
5 × 2 × 1.8 |
4 × 2 × 1.8 |
|
Output T/day |
1.8-2.3 |
1.2-1.8 |
0.8-1.3 |
0.6-1.0 |
0.3-0.6 |
0.2-0.4 |
Friendly reminder: If you want to know further information and technology parameter, please contact with me directly: (Ms Anne) Email: anne.sun80@hotmail.com Skype: spp1219
Mob: 0086-13780978810
| Payment Terms: | TT |
|---|---|
