LM2-45 Diesel Block Making Machine
Product Description
Production Capacity: 400×200×200mm 1000-2000 pcs/8h
Diesel engine: 6 HP
Fuel: Diesel Oil
Forming Cycle: 45-50seconds
Pallet Size: No Need Pallet
Frame Size: 2420*1320*1650 mm
GW: 900kg
Maintaining Field: 500㎡
Stock Field: 500㎡
Raw Material Field: 500㎡
Workers: 2-3
Area of The Workshop Needed: 200㎡
Tech Data of Diesel Pan Mixer
Model: RB260
Engine Model: RB178F
Drum Volume: 260 L
Starting System: Recoil starter
Driving: Manual Push
Packing Size (L*W*H): 1960*1170*1470 mm
Net weight: 357 KG
The Components of LM2-45 Block Making Machine
1. QM4-45 Block Making Machine (Powered by Diesel)
2. Pan Mixer (Powered by Diesel)
3. Hollow Block Mould 400*200*200mm
Package:
1. Two Wooden Boxes without Fumigation or Steel Frame Boxes
2. 8.7m³ 1.25T
Product Image
Img 1
