1.4Mp trinocular biological digital microscope with ccd camera

Model:-
Brand:JPLY
Origin:Made In China
Category:Electronics & Electricity / Other Electrical & Electronic
Label:industrial camera ;m , High-speed camera , USB camera
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Guangzhou Jply Electronic Technology Co., Ltd

Free MemberGuang Dong - China
Live Chat:Last Online:07 Mar, 2018

Product Description

Company Information

As a global camera provider, JPLY is dedicated to balanced sustainability and responsible business. With quality and integrity at our core, we deliver best-in-class camera and related product. JPLY designs and manufactures high performance and user-friendly CCD, CMOS cameras for a vast variety of life science and industrial research applications.



The company consistently delivers ODM/OEM products that are innovative, easy to integrate, cost-effective and on time. Being a leader of camera designer in China, JPLY is developing to a world class brand. We ensure that customers stay with us over multiple product generations by consistently meeting their demands for cutting-edge technology, technical consulting services, integration assistance and the highest manufacturing standards.




Our

JPLY Electronic Technology Co.,Ltd Provide various brand camera gel imaging system maintenance services, we had successfully repaired BIO - RAD the UNIVERSAL HOOD II - S.N. 76 s / 02348 gel imaging system, and it can provide customers with more excellent CCD cameras for the user to choose to replace, suitable for different gel imaging machine maintenance



Maintenance brand

UVP,SIM,KODAK,Alpha,GE Healthcare,BIO-RAD,aplegen,Cleaver,Thmorga so on.





Camera information:



Model

Sensor

Pixel size(μm×μm)

Resolution

Sensibility  V/lux-sec(550nm)

FPS

Shutter

dynamic range (dB)

SNR(dB)

CCD

G1TC01C-M

1/2" CCD Mono

4.65 ×4.65

1.4M(1360x1040)

0.4

20fps

Global shutter

61

44

S1TC01C-M

2/3"SONY ICX285 Mono

6.45×6.45

1.4M(1360x1040,2×2bin)

1.24

20fps

Global shutter

64

74

S1TC05C-M

2/3" 5.0Mega Mono

3.45×3.45

5M

(2456x2058)

0.42

6fps

Global shutter

64

41

CMOS

G1TD01C-M

1/2" CMOS Mono

5.2x5.2

1.3M(1280x1024)

2.1

30fps

Rolling Shutter

68.2

45







Successful Case



BIO-RAD UNIVERSAL HOOD II-S.N. 76S/02348

Our company has successfully help the BIO-RAD UNIVERSAL HOOD II-S.N. 76S/02348 repaired Gel Imaging system, camera specs 1.4M(1360×1024) Pixel Size: 4.6μm×4.6μm.The camera of the instrument has a problem, and the company USES G1TC01M (1.4m 1360 x 1040, 4.65 mu M x 4.65 mu M) to replace the original camera, and it is matched with the corresponding electric variation lens.



Please check as follow:

Product installation picture and real taken pictures:









       Gel Imaging real picture(G1TC01M)


















Payment Terms:T/T

Product Image

1.4Mp trinocular biological digital microscope with ccd camera 1
Img 1
1.4Mp trinocular biological digital microscope with ccd camera 2
Img 2
1.4Mp trinocular biological digital microscope with ccd camera 3
Img 3
