YGS-500M electric magnetic lock

Features:

1. Fail safe: locked when power up

2. Magnet size:267×40×67mm

3. Armature plate:185×16×61mm

4. Holding force:500kg(1200lbs)

5. Current Drain:480mA/12VDC,240mA/24VDC

6. Opening mode: 90 degree swinging door

7. Safety function: Built-in voltage spiker suppressor to protect the lock body and equipments;

8. Special appearance finishing: Aluminum anodic oxidation, lock body and armature have

    been done chemical plating anticorrosion finished.

9. Hanging installation/surface mounted

9. Suitable for wooden door, metal door, fire proof door

10.Unit Weight (Approx.):4.8kg

Function description:

M500M: With LED light;
