| Model: | H47 |
|---|---|
| Brand: | Impinj M4 |
| Origin: | Made In China |
| Category: | Packaging , Printing & Paper / Anti-counterfeiting Products |
| Label: | uhf inlay , rfid labels , uhf rfid |
| Price: |
US $0.086
/ pc
|
| Min. Order: | 5000 pc |
| Live Chat: |  | Last Online:05 Mar, 2023 |
antenna:44 x 44 mm - aluminium
min. die-cut size:50 x 50 mm
delivery format:dry inlay, wet inlay, label
IC available:Impinj
application:True 3D design for apparel
rfidcardlabel.com offer UHF Dry Inlay/UHF Wet Inlay(both of them are transparent, but wet inlay got adhesive on the back). Chips: Alien H3/H4, Impinj M4E/M4D/M4QT/M5/MR6. More detail, please contact us!
Size: Accept Customized
Shape: Accept Customized
Printing: Accept Customized
Matertail: Accept Customized
QTY: NO MOQ LIMITED
we provide OEM packing, design, and manufacture RFID Products, tailor made to meet customer's demand in product identification and authenticity. Welcome to inquiry
|
Item |
Chips |
Dry Inlay Dimension |
Wet Inlay Dimension |
Nominal Read Range |
|
|
AZ-9610/AZ-9710 |
H3 |
44.45*10.325mm |
47.5*13.375mm |
3m |
|
|
AZ-9613 |
H3 |
12*9mm |
19*12.5mm |
20cm |
|
|
AZ-9620 |
H3 |
27*9.7mm |
31*14.7mm |
2m(860~900MHz) |
|
|
AZ-9627 |
H3 |
30*45mm |
34*48mm |
2m |
|
|
AZ-9629 |
H3 |
22.5*22.5mm |
25.5*25.5mm |
3.5m |
|
|
AZ-9630/AZ-9730 |
H3/H4 |
70*9.5mm |
73*12.7mm |
4m |
|
|
AZ-9634 |
H3 |
44*46mm |
47*51mm |
6m |
|
|
AZ-9640/AZ-9740 |
H3/H4 |
94.8*8.15mm |
98.18*12.31mm |
6m |
|
|
AZ-9654 |
H3 |
93*19mm |
96.5*23.2mm |
6m |
|
|
AZ-9662/AZ-9762 |
H3/H4 |
70*17mm |
73.5*21.2mm |
6m |
|
|
AZ-D |
H3 |
95*3mm |
124*7mm |
3m |
|
|
AZ-E |
H3 |
84*3mm |
124*7mm |
3m |
|
|
AZ-H |
H3 |
95*3mm |
124*7mm |
3.5m |
|
|
E41-B |
M4 |
95*8mm |
99*12mm |
6m |
|
|
E41-C |
M4 |
95*8mm |
99*12mm |
6m |
|
|
E42 |
M4 |
68*19.2mm |
73.5*23.2mm |
4m |
|
|
B41 |
M4 |
22*8mm |
26*12mm |
0.3m0.3m(After Special treatmentcan Read over 6 m) |
|
|
B42 |
M4 |
22*8mm |
26*12mm |
0.3m0.3m(After Special treatmentcan Read over 6 m) |
|
|
F43 |
M4 |
26*16mm |
30*20mm |
2m |
|
|
J41 |
M4 |
12*12mm |
\ |
0.22m(Near-Field Antenna) |
|
|
E44 |
M4 |
105*6mm |
109*10mm |
4.5m |
|
|
AZ-M |
M4 |
95*3mm |
124*7mm |
2m |
|
|
H41 |
M4 |
46*30mm |
\ |
2.5m(3D Function) |
|
|
H47 |
M4 |
44*44mm |
50*50mm |
6m(3D Function) |
|
|
CD Inlay |
M4 |
ID: Ф20mm OD: Ф36mm |
ID: Ф15mm OD: Ф39mm |
1.5m |
|
|
YTG-103 |
M4 |
96*8mm |
100*12mm |
6m |
|
|
YTG-130D |
M4 |
60*30mm |
64*34mm |
4m(3D Function) |
|
|
YTG-130D+ (YTG-132D) |
M4 |
60*30mm |
64*34mm |
5m(3D Function) |
|
|
YTG-131 |
M4 |
35*35mm |
39*39mm |
3.5m(3D Function) |
|
|
YTG-150 |
M4 |
70*14mm |
74*18mm |
6m |
|
|
J51 |
M5 |
12*12mm |
\ |
0.22m(Near-Field Antenna) |
|
|
F51 |
M5 |
22.5*22.5mm |
25.5*25.5mm |
0.6m |
|
|
H51 |
M5 |
50*30mm |
\ |
2.9m |
|
|
E51 |
M5 |
95*8mm |
99*12mm |
6m |
|
|
E52 |
M5 |
68*14mm |
73.5*21.2mm |
6m |
|
|
E53 |
M5 |
44*18mm |
48*22mm |
3m |
|
|
YTG-104 |
M5 |
94*8mm |
98*12mm |
6m |
|
|
YTG-151 |
M5 |
70*14mm |
74*18mm |
6m |
|
|
ER 62 |
MR6 |
70*14mm |
74*18mm |
6m |
|
|
AZ-H6 |
MR6 |
68*14mm |
/ |
6m |
|
|
HR61 |
MR6 |
50*30mm |
/ |
5m |
|
|
AR61F |
MR6 |
40*15mm |
/ |
3m |
|
|
AZ-B6 |
MR6 |
44.45*10.33mm |
47.5*13.375mm |
3m |
|
|
AZ-G6 |
MR6 |
50*30mm |
/ |
5m |
|
|
AZ-U61 |
MR6 |
95*8mm |
99*12mm |
6m |
|
|
AZ-U71 |
U CODE 7 |
95*8mm |
99*12mm |
6m |
|
|
AZ-U72 |
U CODE 7 |
70*9.5mm |
73*12.7mm |
4m |
|
|
AZ-U73 |
U CODE 7 |
44.45*10.33mm |
47.5*13.375mm |
3m |
|
|
AZ-H7 |
U CODE 7 |
68*14mm |
74*18mm |
4m |
|
|
AZ-D7 |
U CODE 7 |
95*3mm |
124*7mm |
3m |
|
|
AZ-G7 |
U CODE 7 |
50*30mm |
\ |
3m |
|
|
AZ-M7 |
U CODE 7 |
40*15.5mm |
\ |
2.5m |
|
|
AZ-F7 |
U CODE 7 |
26*16mm |
30*20mm |
1.5m |
Note: 1. Above antenna, can production Label, Paper Card,coupon ticket, PVC Card(Can be customized based on Client's requirement)
2. Adhesive label material choice: coated paper, thermal paper, PP synthetic paper, PET, transparent PVC, Writing Paper
3. Sided adhesive choice: no basic material, PET, PP25 transparent adhesive, Cotton paper glue
4. Sheetfed card / coupon ticket material choice: coated paper, thermal paper
5. Personalization process: UID Printing, Encoding, QRcode/Barcode printing
| Payment Terms: | Paypal, T/T, Western Union |
|---|---|
| Packing: | In Roll |
