Stepless dimming snowflake UV machine with bridge for aututo roller screen print

Model:TM-1050XH
Brand:Tamprinter
Origin:Made In China
Category:Industrial Supplies / Plate Making & Printing Machine
Label:snowflake UV machine , Iceflake uv machine , automatic uv machine
Price: US $10000 / SET
Min. Order:1 SET
Inquire Now Add to Basket

Member Information

Detail

SHENZHEN TAMPRINTER PRINTING MACHIN

Biz MemberGuang Dong - China
Live Chat:
Last Online:12 Jun, 2024

View all products. (210)

Product Description

Electronic dimming snowflake heightening style ultraviolet light curing machine with transmission bridge for full automatic stop cylinder screen press

TM-1050XH is newly designed specially for making snow effect on cigarette and wine packing cases, which also can be used with full automatic screen press or other equipments. It also can be used for drying, dehumidifying and curing other special UV ink of screen printing, dyeing, electroplating and electron circuit board etc.

1. Three groups of UV lamps are independently. Three choice for t he UV intensity separately. The digital meter shows the intensity and life timely.

2. Two groups of conveying system are independent, convey belt speed frequency controlled, the highest speed can be up to 60m/minutes.

3. Three groups of lamps have independent heat removal system, equipped two groups of adsorption.

4. It has conveyor belt rectify a deviation system with adsorption; Adopt imported teflone belt.

Speed 60M/minute
Wrinkle -1 lamp power 30Wx4Pcs
wrinkled-2 UV lamp power 8KWx1Pcs
Curing lamp power 8KWx3Pcs
Effective curing width 1200mm
Conveyor motor power 400Wx2
Adsorption of fan power 1.1Wx2
Exhaust fan power 0.75Wx2
Weight(about) 2200kg
Overall size 4200X1700X1380mm



















Tamprinter Brand Heightened  Wine Case Snowflake Ultraviolet Light Curing Machine, With Conveyor Bridge, Stepless Dimming,  Connected With Cigarette Case Automatic Roller Screen Printing Machine or Automatic Jewelry Box Offset Printing Machine
