| Model: | T100-40 |
|---|---|
| Brand: | SCTI |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Optical Lens & Instrument |
| Label: | infrared telescope , sniperscope , infrared binoculars |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:28 Aug, 2020 |
|
Technical specification
|
||
|
Thermal characteristic
|
Detector
|
Uncooled amorphous silicon FPA
|
|
Array format/Pixel pitch
|
384x288/25um
|
|
|
Sensitivity
|
≤60mk@ 300K,50HZ
|
|
|
Frame rate
|
50Hz
|
|
|
Spectral range
|
8～14um
|
|
|
Lens
|
40mm F#=0.8
|
|
|
FOV
|
13.8°(H) x 10.3°(V)
|
|
|
Spatial Resolution
|
0.4mrad
|
|
|
Focus
|
Manual focus
|
|
|
Image processing
|
Nonuniformity calibration
|
No shutting technology
|
|
Instantaneous boot
|
〈3s
|
|
|
Noise reduction
|
Digital filter
|
|
|
Image definition
|
768X576(CCIR)
|
|
|
Image frame rate
|
50Hz(PAL)
|
|
|
Polarity
|
White hot /Black hot
|
|
|
Image output
|
OLED 800x600 resolution
|
|
|
OLED display adjustment
|
Brightness/Contrast adjust
|
|
|
OLED eyepiece
|
Dust proof
|
|
|
Image/video storage
|
SD Card
|
16G
|
|
Image format
|
JPEG
|
|
|
Video format
|
AVI
|
|
|
Power
|
Working voltage range
|
DC: +2.6V～+5.5V
|
|
Battery
|
3 AA betteries
|
|
|
Power consumption
|
〈2W
|
|
|
Continuous working time
|
>4 hours
|
|
|
Over voltage protection
|
Yes
|
|
|
Reserve voltage protection
|
Yes
|
|
|
Environmental parameter
|
Working temperature range
|
-20℃～60℃（Typical）；
|
|
Storage temperature range
|
-40℃～85℃
|
|
|
Humidity
|
10%～95% Non-condensing
|
|
|
Encapsulation
|
IP67
|
|
|
Drop test
|
1 meter
|
|
|
Physical parameter
|
Weight
|
≤0.8kg No betteries
|
|
Dimension
|
212mmx73x55mm
|
|
|
Interface
|
Power port
|
Yes
|
|
Serial port
|
RS-232
|
|
|
USB port
|
Yes
|
|
|
Video output port
|
Yes
|
|
|
Accessories
|
Cable
|
With USB, video connector and RS232 cable
|
|
Batteries
|
3 AA batteries Ni-H chargeable with charger
|
|
|
Bag
|
Carry bag
|
|
| Payment Terms: | TT |
|---|---|
