Model

LCF-VDIRCN650

Specification

1/3″SONY

DSP

CXD4140GG (SONY EFFIO)

Imaging Device

ICX673BK/ICX672BK

Total Pixels

1020(H) x 596(V)

Effective Pixels

976(H) x 582(V)

Scanning System

2:1 Interlace

Synchronization

Internal

Horizontal Resolution

650TV Lines

Video Output

CVBS : 1.0Vp-p,75Ωcomposite

S/N Signal

52dB(AGC off)

Min. Illumination

0.01Lux,IR/ON:0Lux

IRIS Adjustment

Auto

ESC

Auto/Manual(1/50(60)~1/120,000sec)

OSD Language

English/Chinese

BLC

Auto

Day/Night selection

Auto

Gain Control

Auto

White Balance

AWB/AWC (1,700°K~11,000°K)

Motion Detection

On/Off(Programmable8 zones)

Privacy Masking

On/Off(Programmable12 zones)

2 DNR

On / Off

IR

12PCS

IR Distance

0-15M

Lens

3.6/6mm

Input Voltage

DC8V - DC18V

Power Consumption

MAX 1.5W

Operating Temp/Hum

-10℃~+50℃/30%RH~80%RH

Storage Temp/Hum

-20℃~+60℃/20%RH~90%RH

Weight

Gross weight: 180g, Net weight: 150g

Dimension

￠54mm*H44.7mm
