LED AR111 G53 10W COB Dimming Spotlight Lamps Reflector Bulbs
Product Description
AR111 DC20V 500mA Dimmable Driver specification
1 General Data
1.1 Rated Voltage [V] 220~240
1.2 Wide Voltage Range[V] 180~260
1.3 Surge Voltage [V] 500
1.4 Frequency [Hz] 50/60
1.5 Output Voltage with Load DC20V
1.6 Input Current [mA] 77
1.7 Max.Output Current [mA] 500
1.8 Max.Input Wattage[W] 12.4(+10%/-15%)
1.9 Output Wattage[W] 10.0(+10%/-15%)
1.10 Power Factor 0.7
1.11 Classification of Installation and Use Built-in
1.12 Max. Casing Temperature [℃] 85
1.13 Ambient Temperature Range [℃] -20 to +40
1.14 Luminaires of Protection Class II
1.15 Open Circuit Protection Yes
1.16 Short Failure Protection Yes
1.17 Dimming range 100%~10%
Product Image
