| Model: | YG-F-TUBE |
|---|---|
| Brand: | YIGUANG |
| Origin: | Made In China |
| Category: | Chemicals / Rubber Materials |
| Label: | silicone foam tube , silicone sponge tube , silicone foam sponge |
| Price: |
-
|
| Min. Order: | 200 m |
| Last Online:28 Oct, 2016 |
sample is free of charge
1)Imported technology
2)Foamed rubber,similiar to sponge ,
3)Inner shape be customized
4)ASTM Standard
[Major Parameter]
|
Capability |
Unit |
Number |
Test Standard |
|
Tensile Strength: |
M pa |
30 |
ASTM D412 |
|
Breaking Strength |
K n/m |
55 |
ASTM D1458 |
|
Elongation |
% |
200 |
ASTM D412 |
|
Hardness |
Shore A |
20±3 |
ASTM 2240 |
|
Temperature Range |
°C |
-60-250 |
En344 |
|
Density |
g/cc |
0.3 -0.9 |
ASTM D792 |
|
Thermal Conductivity |
w/m*k |
0.9 |
ASTM D5470 |
|
Breakdown Voltage |
VAC |
>3000 |
ASTM D149 |
|
Dielectric Constant |
1000HZ |
5.5 |
ASTM D150 |
|
Volume Resistance |
Ohm*m |
1.0*10*11 |
ASTM D257 |
|
Fireproofing Grade |
----- |
----- |
ASTM U.L |
[Specification Available (mm)]
1*3, 2*4, 3*5, 4*6, 5*7, 6*9, 8*12, 10*14, 10*20, 12*17, 15*20
[Color]
Red,Grey,White,Black,Blue,Green,Primary Colors
[Feature]
(1) Excellent heat resistance,nontoxic,insulating,temperature resistance - 60-250°C.
(2) Length can be cut,
(3) Outstanding flame resistance
(4) Excellent mechanical strength
| Payment Terms: | TT/Paypal |
|---|---|
