| Model: | 1183 |
|---|---|
| Brand: | .3M |
| Origin: | Made In United States |
| Category: | Electronics & Electricity / Electric Parts & Materials |
| Label: | 3M 1183 , 3M EMI Tape , 3M Copper Foil Tape |
| Price: |
-
|
| Min. Order: | 1 roll |
| Live Chat: | Last Online:11 Nov, 2021 |
3M 1183 EMI Tin-Plated Copper Foil Shielding Tape has a dead soft, tin plated copper foil carrier, coated on one side with a conductive acrylic adhesive. The tin plating provides improved corrosion resistance that can be easily soldered. The conductive particles in the adhesive provides low contact resistance between the substrate and the backing to drain static charge. The acrylic adhesive also has good resistance to heat, oxidation, solvents and oils.
3M 1183 is designed for applications requiring reliable point-to-point electrical contact, particularly EMI shielding, grounding and static charge draining.
3M 1183 has a UL 510 flame rating and is available in non-standard slit rolls, sheets and custom shapes.
