Big size touch screen kiosk: Usually we call those touch screen kiosks which with 32''37''42''...70'' monitor as big size touch screen kiosk. Normally, for 32''37'' big size touch screen kiosk, we always use TFT LCD monitor. For touch screen kiosk which is bigger than 42'', we need use LED monitor, not only because it is with low power consumption, but also it is good quality with better price. Till now, the biggesr touch screen kiosk we produce is 70'' touch screen kiosk. If you need bigger one, warm welcome to contact us.
This kiosk is designed as LED screen advertising equipment. As a free standing terminal machine, it is a best choice to be an advertising player.
1)55'' grade A+ LED display
2)55'' duarable steel lcd screen advertising enclosure/cabinet/case
3)55''Infrared touch panel, multi touch for choice.
4)Powerful Embed computer(upgrade available)
5)Operating system, wired internet access.
Note: the above components can be ordered seperately, such as you could order touch panel only, or kiosk enclosure only.
1)touch screen: Infrared touch panel, multi touch for choice.
a. Infrared touch screen kiosk
b. Resolution: 4096*4096
c. Deviation of Error: ±<1.0%
d. Surface Hardness: Mohs' hardness rating of 7
e. Hitting Life Expectancy: 50,000,000 cycle times
f. Support software: Windows, Linux...
g. Transmittance: 92%~95%
2)LED monitor: 100% new LG or Samsung Grade A+ monitor
a. Resolution: 1920X1080, support full HD
b. Brightness: 450cd/m2
c. Contrast ration: 1000: 1
d. Contact Bounce: 5ms
e. lifelong: more than 50 000 hours
f. Ratio: 16:9 or 4:3
3)Powerful Embed PC:
a. CPU: Intel J1900 2.0ghz CPU (Optional)
Motherboard: Industrial mainboard
b. Storage: 120GB SSD,HDD for choice.
c. RAM: Kingmax DDRIII 4GB(optional)
d. Ports: USB ports, RS-232 ports
e. load speakers, cooling fans, intergrate viedo card&Graphics card, RJ45 interface, steel box for embed computer
a. 1.2mm~1.5mm cold rolled steel, 2.00mm available.
b. build in power control panel, and hi-fi-speaker
c. RJ45 interface, 2 USB port, 8 usbs and more are available.
5)working enviroment: 0~45 degree, 30%~90% relative humidity
The following additional devices are available:
1. Wifi, 3G modem, GPRS, Bluetooth
2. Finger printer, RFID card reader
3. Digital camera, web camera, surveillance camera
The Color is optional, based on Pantone chart.
After packaged with wooden case, this kiosk will be more than 120kgs, about 1cbm. So if it's not too urge, ship by seafreight will be cheaper.
1. To Saudi Arabia and UAE, CO and SASO is necessary.
2. To Africa countries, there are few ships .
Notes: We just only provide all of the hardware
With our own factories in Shenzhen, we have a strictly quality control system, to provide you best product with best price.
|Price Terms:||EXW price
|Packing:||foam, carton, wooden case
|Lead Time:||Usually 15 working days after deposit received
