Duct sensors for humidity & temperature 1
  • Duct sensors for humidity & temperature 1

Duct sensors for humidity & temperature

Model:QFM31...QFM41
Brand:SIEMENS (LANDIS)
Origin:Made In Germany
Category:Construction & Decoration / Building Heater
Label:LANDIS , sensors for humidity , QFM41
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Guangzhou Easycom Automation Equipment Co.,Ltd.

Biz MemberGuang Dong - China
Live Chat:
点击这里给我发消息Last Online:28 Aug, 2023

Product Description

Type reference  Temperature measuring range Temperature signal output Humidity measuring range Humidity signal output Operating voltage Measured value display
QFM3100 none none 0…100% active, DC 0...10 V   AC 24 V or DC 13,5…35 V no
QFM3101  none none 0…100% active, 4-20mA  DC 13,5…35 V no
QFM3160 0..50'C/-40…+70'C/-35…+35'C active, DC 0...10 V 0…100% active, DC 0...10 V   AC 24 V or DC 13,5…35 V no
QFM3160D  0..50'C/-40…+70'C/-35…+35'C active, DC 0...10 V  0…100% active, DC 0...10 V   AC 24 V or DC 13,5…35 V yes
QFM3171  0..50'C/-40…+70'C/-35…+35'C active, 4-20mA 0…100% active, 4-20mA  DC 13,5…35 V no
QFM3171D  0..50'C/-40…+70'C/-35…+35'C active, 4-20mA 0…100% active, 4-20mA  DC 13,5…35 V yes

Specifications:Operating voltage AC 24 V / DC 13.5...35 V
• Signal output DC 0...10 V / 4…20 mA for relative humidity and temperature
• Very high measuring accuracy across the entire measuring range
• Function test
• Capacitive humidity measurement
• Range of use −40…+70 °C / 0…100 % r. h.
with LCD display −25…+70 °C / 0…100 % r. F.
Use
The QFM31… is for use in ventilation and air conditioning plants where high accuracy
and short response times for measuring relative humidity are required. The measuring
range covers the entire humidity range of 0…100 %.
• Storage and production facilities in the paper, textile, pharmaceutical, food, chemical
and electronics industry, etc.
• Laboratories
• Hospitals
• Computer and EDP centers
• Indoor swimming pools
• Greenhouses
The QFM31… is used as a
• control sensors in the supply or extract air
• limit sensor for maximum limitation of supply air humidity after a steam humidifier
• limit sensor, e.g. for measured value indication or for connection to a building
automation and control system
• sensor for enthalpy and absolute humidity, together with the AQF61.1 (refer to Data
Sheet N1899) or SEZ220 (refer to Data Sheet N5146)
Export Markets:BUILDING TECHNOLOGT ,BULIDING AUTOMATION
Min Order:1
Ship Date:3 days

Product Image

Duct sensors for humidity & temperature 1
Img 1
