Technology specifications

Frequency

2.4GHz--2.5GHz ISM

Identify direction

Directional

Antenna

15dbi build-in antenna

RF power range

-18.0dBm-0.0dBm( adjusted by 32 grade)

Receiving sensitivity

-90.0dBm

Operating mode

FHSS or fixed frequency(set by software)

Modulation

GFSK

Reading range

0~200m adjustable

RSSI reader can be adjusted less than 10m

Anti-collision

Up to 1000 tags read simultaneously

Buffer capacity

2000 tags data

Communication speed

25kbps, 1Mbps, 2Mbps(adjustable)

Communication interface

RS-232, RS-485, Ethernet ,Wiegand26/34/42/50, Ethernet

Input and output

1 triggering input, 1 relay output

Optional function

2 Relay, CAN, RSSI, ID-Match, Offline, Time

Current/Voltage

AC input: 100~240V, 50/60Hz 1.2A;

DC output: 5V/1A

Product size

225mm*225mm*100mm

Packing size

435mm*290mm*130mm

Gross weight

2.85kg

Net weight

1.82kg

Working temperature

－20℃~+70℃ (-4οF~+158οF)

Storage temperature

－40℃~+85℃ (-40οF~185οF)

Accessories

DC5V/1A adapter, Power cable, RS-232 cable, Ethernet cable, Mounting bracket

Working status indication

Buzzer
