| Model: | 7mm-72.5mm |
|---|---|
| Brand: | TongFeng |
| Origin: | - |
| Category: | Construction & Decoration / Pipe, Tube & Parts / Pipe Fittings |
| Label: | PVC coated , flexible conduit , metal conduit |
| Price: |
US $2
/ pc
|
| Min. Order: | 200 pc |
| Live Chat: |  | Last Online:08 Apr, 2024 |
PVC Coated Interlock Stainless Steel Flexible Conduit
Product construction: interlock
Product material: stainless steel
Surface finish: white PVC jacket
Aim at wiring protection of equipments that used in latent explosion environment (offshore platforms, Petrochemical Equipment, mine, flour mill and other equipments and protective system), especially introduce this hose passed ATEX certification.
Application: It applies in electric and non-electric equipment, machine products and industry devices in all latent explosive environment also uses in control devices and equipments in non-explosive environment to maintain the safety of equipment and instrument or protect the normal operation of the system.
Product Specification
|
Type |
Inch |
(mm)I.D. |
(mm)O.D. |
(mm)O.D.+ PVC |
Packing |
|
P040070C2S1 |
— |
4.0 |
6.0 |
7.0 |
100 |
|
P046080C2S1 |
— |
4.6 |
6.6 |
8.0 |
100 |
|
P050080C2S1 |
— |
5.0 |
7.0 |
8.0 |
100 |
|
P054095C2S1 |
— |
5.4 |
7.8 |
9.5 |
100 |
|
P059100C2S1 |
— |
5.9 |
8.4 |
10.0 |
100 |
|
P066100C2S1 |
— |
6.6 |
9.0 |
10.0 |
100 |
|
P095150C2S1 |
1/4" |
9.5 |
12.5 |
15.0 |
50 |
|
S100150C2S1 |
— |
10.0 |
12.5 |
15.0 |
50 |
|
S125177C2S1 |
3/8" |
12.5 |
15.7 |
17.7 |
50 |
|
S161213C2S1 |
1/2" |
16.1 |
19.5 |
21.3 |
50 |
PVC Coated Squarlock Stainless Steel Flexible Conduit
Construction: Squarelock
material: Stainless steel. Aluminum, Brass
Surface disposal: PVC Jacket or braiding
Product Specification
1. Various materials for the option of customers: stainless steel, galvanized steel, aluminum, brass
2. High tensile resistant, strong vandalism resistant, fatigue resistant, impact resistant, high corrosion resistant and high torque resistant etc.
3. Can add PVC coating or wire braiding on the flexible metal tube to achieve effect of water proof and explosion proof.
4. Superior flexible, smooth, easy for installation and position.
5. Can be installed directly, do not need preset tube or wire.
6. Smooth internal surface, easy to pull wire through, supply various connectors and junction boxes for easy installation.
7. Advanced design, reasonable construction, stable performance, superior installation and high flame/water proof.
Construction: Squarelock
Material: Stainless steel. Aluminum, Brass
Other material: Stainless steel. Aluminum, Brass
Surface disposal: PVC Jacket or Braiding
Product Specification
|
Type |
Inch |
(mm)I.D. |
(mm)O.D. |
(mm)O.D.+PVC |
Packing(M) |
|
P040070S2D1 |
- |
4.0 |
6.0 |
7.0 |
100 |
|
P046080S2D1 |
- |
4.6 |
6.6 |
8.0 |
100 |
|
P050080S2D1 |
- |
5.0 |
7.0 |
8.0 |
100 |
|
P054095S2D1 |
- |
5.4 |
7.8 |
9.5 |
100 |
|
P059100S2D1 |
- |
5.9 |
8.4 |
10.0 |
100 |
|
P066100S2D1 |
- |
6.6 |
9.0 |
10.0 |
100 |
|
P095150S2D1 |
1/4 |
9.5 |
12.5 |
13.2 |
50 |
|
S125177S2D1 |
3/8 |
12.5 |
15.7 |
17.7 |
50 |
|
S161213S2D1 |
1/2 |
16.1 |
19.5 |
21.3 |
50 |
|
S191245S2D1 |
- |
19.1 |
22.2 |
24.5 |
50 |
|
P208267S2D1 |
3/4 |
20.8 |
24.3 |
26.7 |
40 |
|
P220280S2D1 |
- |
22.0 |
25.7 |
28.0 |
40 |
|
P260330S2D1 |
1 |
26.0 |
30.0 |
33.0 |
30 |
|
P340422S2D1 |
1-1/4 |
34.0 |
39.0 |
42.2 |
30 |
|
P390478S2D1 |
1-1/2 |
39.0 |
44.0 |
47.8 |
20 |
|
P510594S2D1 |
2 |
51.0 |
56.0 |
59.4 |
10 |
|
P630725S2D1 |
2-1/2 |
63.0 |
67.5 |
72.5 |
10 |
