Automatic Wire Stripping Cutting & Twisting Machine

Model:X-5016
Brand:XUXIN
Origin:Made In China
Category:Industrial Supplies / Electrical & Electronic Product Equipment
Label:Twisting Machine , Stripping Machine , wire cutting machine
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Kunshan Xuxin Industrial Equipment Co.,Ltd

Biz MemberJiang Su - China
Live Chat:
点击这里给我发消息Last Online:19 Apr, 2021

Product Description

Automatic Wire Stripping Cutting & Twisting Machine

The model is a factory successfully developed its own high-tech products. Main widely used in the electronics industry, electric power, injection molding equipment, electric tools, automobile and motorbike industry, electrical machinery, electrical appliances, air conditioners, washing machines, electronic instruments, toys, lamps, transformers, connectors and other types of products, wiring harness processing. Appropriate wire stripping:PVC/teflon/silica gel line /Glass fiber etc. This product USES the LCD screen people dialogue mode, with nice appearance, simple operation, convenient maintenance, stable performance, speed, precision higher character. Wire length can set arbitrary, according to the customer request free to change, different degree of finish off wire, also have on row line, sheath line, power lines and bushing cutting functions.

Model:

X-5016

Power:

AC 110V/220V/ 50/60Hz

Power:

Rated 450W

Display:

Full English LCD Display

Cutting length:

1mm-60000mm

Twisting length

Line head 0-35, line tail 0-20

Twisting way

Both sides or one side

Stripping length:

Line head 0-35, line tail 0-20

Cutting Tolerance:

(0.0001xL) mm

Max. Middle Stripping Section:

16

Core cross-section cut-line:

double 0.1~2.5mm² ( AWG16#-AWG32#)

Single up to 4.5mm²

Conduit diameter:

Φ6

Appropriate wire stripping:

PVC, Teflon, glass and wire

Blade Material:

Hard tungsten steel

 Stripper speed (Article / h):

L=100mm, 3000-10000pcs/h

 Drive Mode:

Four-wheel drive

Weight:

40kg

Dimensions:

450*365*265(mm)

Adjustable speed

0-6




Product Image

Automatic Wire Stripping Cutting & Twisting Machine 1
Img 1
Automatic Wire Stripping Cutting & Twisting Machine 2
Img 2
Automatic Wire Stripping Cutting & Twisting Machine 3
Img 3
Automatic Wire Stripping Cutting & Twisting Machine 4
Img 4
