NEW!!! LILLIPUT 9.7'' Field Monitor with SDI,Component,HDMI input
Product Description
Lilliput 9.7"3G-SDI LCD Field Monitor with Advanced Functions for Full HD Camcorder and Video Camera.
969A/P (with BNC interfaces)
969A/O/P (with BNC interfaces, HDMI output)
969A/S (with BNC interfaces, HDMI output, 3G-SDI input / output)
969B/P (without BNC interfaces)
969B/O/P (without BNC interfaces, with HDMI output)
IPS panel wide viewing angles,
High resolution: 1024× 768,
High brightness: 420CD/,
High contrast: 600: 1,
Dual HDMI input,
3G-SDI input / output,
USB 5V output for charging,
Wide voltage: DC 7-24V,
TALLY interface with indicating light,
Gimbal bracket for installation,
Suitcase make monitor watertight, crushproof and dust proof.
Advanced Functions:
Peaking Filter, False Colors, Histogram, Exposure, Camera, Center Marker, Pixel-to-Pixel, Color Bar, Screen Marker, Aspect Ratio, Check Field, Underscan/Overscan, Freeze Input, H/V Delay, 8x Zoom, Picture-in-Picture.
| Parameters: |
| Panel |
9.7” LED |
| Physical Resolution |
1024× 768, support 1920× 1080 |
| Aspect Ratio |
4: 3 |
| Brightness |
420cd/m² |
| Contrast |
900: 1 |
| Viewing Angle |
178° / 178° (H/V) |
| Input Signal |
3G-SDI,HDMI, YPbPr, AV, TALLY |
| Output Signal |
HDMI(optional), YPbPr, AV, USB(5V) |
| Audio |
Speaker× 1(built-in), Ear Phone Slot× 1(built-in) |
| Current |
≤ 1500mA |
| Input Voltage |
DC 7-24V(XLR Connector) |
| Battery Plate |
V-mount, Anton Bauer mount, F-970, QM91D, DU21, LP-E6 |
| Power Consumption |
≤ 18W |
| Operating Temperature |
-20º C ~ 60º C |
| Storage Temperature |
-30º C~ 70º C |
| Dimension(LWD) |
246× 224× 31mm/167.5mm(with cover open) |
| Weight |
1068g / 1388g (with cover) |
| Accessories: |
| Flexible folding sun shade cover |
1 piece |
| Battery plate bracket |
1 piece |
| Battery plate (F-970, QM91D, DU21 or LP-E6) |
2pieces |
| HDMI A/A cable |
1 piece |
| DC 12V power adapter (XLR connector) |
1 piece |
| TALLY connector |
1 piece |
| Manual |
1 copy |
| Gimbal bracket |
1 piece (optional) |
| V-mount battery plate |
1 piece (optional) |
| Anton Bauer mount battery plate |
1 piece (optional) |
| Suitcase |
1 piece (optional) |
Product Image
Img 1
Img 2
Img 3
Img 4
Img 5
