FG250 Capsule Filling Machine

Model:	FG-250
Brand:	sunhang
Origin:	Made In China
Category:	Industrial Supplies / Pharmaceutic Machine
Label:	Capsule machine , Fill capsule machine , Capsule equipment
Price:	US $2500 / set
Min. Order:	1 set

Inquire Now Add to Basket

Member Information

Sunhang Pharmaceutical Machinery Co., Limited

Biz MemberShang Hai - China

Live Chat:

Last Online:24 Apr, 2024

Product Description

FG250 Capsule Filling Machine

This machine is the company to 400, based on carefully designed new products. Set of three machines (cap, body arranged machine, locking machine) as a whole, compared with reduced operator, reduced workplace. For small pharmaceutical factory, hospital preparation subjects, laboratory test, plant health products and other units of the capsules, the fit, locking.
Use: 00 # 4 # Capsule cap and body of the fit and powder filling.
Features:
1, simple operation, easy maintenance, low power consumption, high efficiency, and the use of a machine.
2, the key components, hoppers, tops, stainless steel, stainless steel body as a whole, in line with GMP standards;
3, simple structure, small power consumption, high efficiency, maintenance, cleaning is easy, very low failure rate.
4, for 00 #, 0 #, 1 #, 2 #, 3 #, 4 # capsules of the fit for various types of capsules filled with a variety of powder and granules;
5, easy to operate, ten minutes to completely learn how to operate; easy replacement model, 20 minutes to complete the replacement of the template;
6, 100% capsule filling, capsule more than 99.8% pass rate, and will not damage the capsule.
Use: 00 # 4 # Capsule cap and body of the fit and powder filling

Main Technical Specifications:

Ability to work	30-50 seconds depending on the operating proficiency / time range, each 255, 16-25 ten thousand middle class
Power supply	AC 220V 50Hz+-15%
Power consumption	470W
Pass rate	≥99.8％
Accuracy of load	W±5％
Template accuracy	R0.05mm
Dimensions	1150×560×1050mm
Pressure limiting lock	800kg
Weight	160Kg
