Features
- MIMO technology improves data throughput and range over existing 802.11b/g products
- Add high-speed Wireless-N (draft 802.11n) Internet access to any USB enabled computer
- Download music & movies, surf the internet and e-mail up to 5 times faster than previous generation wireless networks (Wireless 802.11g)
- Offers greater coverage than Wireless-G networks for internet access throughout your home or office
- Works with older Wireless-G and Wireless-B networks
- WiFi Protected Setup (WPS) simplifies setup and operation
- Operating distance of up to 300 feet indoor, and up to 900 feet in open space
- Data transfer rate of up to 150Mbps
- Supports USB 2.0 interface, backward compatible to USB 1.1 and 1.2
- Enhanced WEP and WPA wireless security for protected Internet access
- 64-bit / 128-bit WEP (Wired Equivalent Privacy), TKIP, AES 2.400GHz ISM
- Frequency Band Modulation Method: QPSK / BPSK / 16-QAM / 64-QAM
- Supports Ad Hoc and Infrastructure modes
- Supports IEEE 802.11e standard
Specifications
|
Wireless Standards
|
IEEE 802.11n (draft)
IEEE 802.11g
IEEE 802.11b
|
|
Host Interface
|
High speed USB2.0/1.1 interface
|
|
Data Rate
|
802.11n: up to 300Mbps (downlink) and 150Mbps (uplink)
802.11g: 54 / 48 / 36 / 24 / 18/ 12 / 9 / 6 Mbps auto fallback
802.11b: 11 / 5.5 / 2 / 1 Mbps auto fallback
|
|
Frequency Band
|
2.4GHz ISM (Industrial Scientific Medical) Band
|
|
Chipset
|
Ralink 3070L
|
|
RF Frequency
|
2412 ~ 2462 MHz (North America)
2412 ~ 2472 MHz (Europe)
2412 ~ 2484 MHz (Japan)
|
|
Radio Channel
|
1 ~ 14 channels (Universal Domain Selection)
|
|
Range Coverage
|
Up to 3 times farther range than 802.11g
|
|
Antenna type
|
Integrated Antenna
|
|
Roaming
|
Full mobility and seamless roaming from cell to cell
|
|
RF Output Power
|
13 ~17 dBm (Typical)
|
|
Modulation
|
11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
|
|
Data Security
|
64/128-bit WEP Encryption
WPA, WPA-PSK, WPA2, WPA2-PSK. TKIP/AES
|
|
Network
|
Auto-switch to use 802.11n or 802.11g or 802.11b mode
Supports Ad-Hoc, Infrastructure WLAN network
Wireless roaming
Data rate auto fall-back under noisy environment or longer range distance
Site Survey with Profile function
|
|
Configuration & Management
|
Plug-and-Play setup and installation
Management Utility supports 2000 / XP/ Vista
|
|
Media Access Control
|
CSMA/CA with ACK
|
|
LED Indicator
|
Link/Active ( Green )
|
|
Operating System
|
Windows 2000, XP 32/64-bit, Vista 32/64-bit，
Linux and MAC OS X
|
|
Environment
|
Operating Temperature: 0oC to 40oC
Storage Temperature: -20oC to 75oC
Operating Humidity: 10% ~ 90% (Non Condensing)
Storage Humidity: 5% ~ 95% (Non Condensing)
|
|
Size
|
39.5*13.5*4cm
|
