Technical reference:
Max Lifting Moment: 11000 (KG. M)
Working Pressure: 25 (MPa)
Slewing Angle: 370°
Working Angle: 0-72°
Gear Pump Delivery Capacity: 63(L/min)
Input Power: 32(KN)
Fuel Tank Volume: 90(L)
Installation Space: 1000(mm)
Dimension: 2023+3147+2830+260(mm)
Lifting Mass and Working Radius: 4500/3, 3400/4, 2720/5, 2290/6, 1890/7, 1680/8, 1480/9
(Reference data above exclude the grapple)
click for larger image
