| Model: | YC628-401 |
|---|---|
| Brand: | YoucTech |
| Origin: | Made In China |
| Category: | Computers & AV Digital / Computer Accessories / Printer |
| Label: | thermal mechanism , FTP628MCL401 , FTP627MCL401 |
| Price: |
US $20
/ pc
|
| Min. Order: | 100 pc |
| Live Chat: | Last Online:28 Nov, 2022 |
58mm thermal printer head mechanism,
Fujitsu FTP-628MCL401, FTP-627MCL401 compatible,
with auto cut feature,
Controller board in RS232, TTL interface available.
Easy paper loading, compact design & lightweight, out-of paper detection, low noise, long life service (50km, 100miliion pulse)
Printing method: Thermal line DOT printing
Number of dots/line: 384 (for 8V), 432 (for 24V)
Resolution: 8
Printing width (mm) : 48
Paper width (mm) : 58
Printing speed: 85mm/s(8.5V), 120mm/s(24V)
Dot pitch (mm) : 0.125
LxWxH (mm): 42.2*81.2x21.8
Weight (g) : Approx. 90
Life span: 50KM & 100 million pulse
Head temperature detection: By thermistor
Out of paper detection: By Photo interrupter
Working power voltage 7.2V - 8.5V, 24V
Working logic voltage 5.0V, 3.3V
Compatibility: Fujitsu FTP-628MCL401, FTP-627MCL401
Application: POS printers, Kiosk receipt printers, cash registers, ticket printers, panel printers, mobile printers, mini portable printers, label machines, queuing machines, banking terminals, medical equipments, desktop printers
| Price Terms: | FOB Xiamen |
|---|---|
| Payment Terms: | TT/LC/Western union |
| Packing: | ANTI STATIC PACKING, MTR BOX |
| Lead Time: | 7 days |
| Standards Certificate: | Rohs, CE |
