| Model: | GFC-34 |
|---|---|
| Brand: | Cummins |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Power & Generating Sets |
| Label: | cummins generator , diesel generator set , power generator |
| Price: |
US $5900
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:04 Jan, 2017 |
|
MODEL
|
GF-C34kw/42.5KVA
|
|
Powered by Cummins Engine
|
|
|
Prime Power (50HZ)
|
34KW/42.5KVA
|
|
Standby Power (50HZ)
|
36kw/45KVA
|
|
Power Factor
|
0.8
|
|
Phase Wires
|
3-phases 4-Wires
|
|
Start Model
|
Electric
|
|
Protection
|
Low oil-pressure, High water temperature, Over-speed, Over-current
|
|
Engine Model
|
4BT3.9-G2
|
|
Cylinders
|
4
|
|
Cylinder Arrangement
|
L
|
|
Bore x Stroke(mm)
|
102X 120
|
|
Compression Ratio
|
16.5:1
|
|
Speed
|
1500rpm
|
|
Cooling Method
|
Water – cooled
|
|
Starting Method
|
24V DC electrical start
|
|
Full Load Diesel Consumption (L/H)
|
9
|
|
Engine Displacement (L)
|
3.9
|
|
Inspiration (L)
|
Natural
|
|
Lube Volume (L)
|
9.5
|
|
Coolant Volume (L)
|
20
|
|
Noise (Db)
|
≤ 80
|
|
Alternator Model
|
Stamford Copy 224C
|
|
Voltage
|
According to customers choice
|
|
Protection
|
IP23
|
|
Voltage Regulation
|
±4%
|
|
Insulation Class
|
H
|
|
Voltage Control
|
AVR
|
|
Net Weigh (KGS)
|
950
|
|
Dimensions (L x W x H) mm
|
2300*1000*1400
|
|
Optional
|
|
|
|
ATS(auto transfer switch)
|
|
|
Battery Charger
|
|
|
Base Fuel Tank (for open type)
|
| Payment Terms: | T/T L/C at sight |
|---|---|
