Home Security Wi-Fi IP Camera

Model:H7835WIP
Brand:Honghui or OEM
Origin:Made In China
Category:Security & Protection / Surveillance Equipment
Label:Wi-Fi IP Camera , IP Came , Home Security Camera
Price: US $69 / Set
Min. Order:500 Set
Inquire Now Add to Basket

Member Information

Detail

HONGHUI ELECTRONIC CO., LTD.

Free MemberGuang Dong - China
Live Chat:Last Online:15 Sep, 2015

Product Description

H7835WIP Home Security Wi-Fi IP Camera

Introductions

This is the newest Home Security Wi-Fi IP Camera, universal power supply can be used all over the world, Supports 8 wireless remote controllers, with 64 wireless zones(8 groups, and 8 zones per group) could connect any wireless sensors or detectorssuch as Door Magnetic Sensor, PIR Motion Detector, Microwave Infrared Intelligent Intrusion Detector, Curtain PIR Motion Detector, Smoke Detector, GAS Detector, Carbon Monoxide Detector, Vibration Detector, Active Infrared Intrusion Detector, and Correlation Type Infrared Fence, etc.

View more, do more, and protect more with the clarity and mobile control of Honghui Pan & Tilt Day/Night Home Security Wi-Fi IP Camera. Download the free app and monitor your home or business – anywhere, anytime – on your smartphone or tablet pc. Experience the confident clarity and total control with the ultra-smooth pan/tilt and two-way audio functions. Integrated motion-sensing and night-vision technology provides around-the-clock surveillance. With simple installation, you’ll have an effective, affordable home or business surveillance IP camera solution up and running in no time.



Features of the Home Security Wi-Fi IP Camera

Supports Wi-Fi B/G/N

Supports Android/IOS APPs

Supports real time video and audio chat

Supports movement detecting, PIR function

Supports night vision function

Supports IRCUT technology

Easy software operation

Supports waterproof

Super fast connection, less than 1 sec

Supports unlocking

Power Supply: DC5V/1A

Audio: 2 x 0.5W speaker and sensitive MIC

Video transmission standard: VGA720P

Sensor type: CMOS (1/3") 2Mega Pixels

64 wireless zones (8 groups, and 8 zones per group) could connect any wireless sensors or detectors

Receiving code: ASK

Transmission frequency: 315MHz or 433MHz



Specifications of the Home Security Wi-Fi IP Camera

Model: H7835WIP

Communication

Receiving code

ASK

Transmission frequency

315MHz or 433MHz

Remote Controller

Supports 8 wireless remote controllers

Wireless Zones

64 wireless zones (8 groups, and 8 zones per group)

Features

System security

Account, password authority management

Free DDNS

Free DDNS, Supports dynamic IP

View by phone

Supports HD picture  IOS, Android mobile view (IOS 4.3, Android OS 2.3 above)

Local Storage

Supports up to 32GB Micro SD card, 24-hour loop recording.

Monitor Advantage

Supports PC computer monitoring, smartphone multi-picture view.

PnP

Plug & Play, 99% penetration rate, Easy to setup: 1. connect the network cable and power adapter, 2.install APP, scan UID code to add camera.  3, Click online camera to view the camera.

Sever cluster

Using Amazon Cloud PnP server cluster, intelligent application and super stable

UID Technology

UID scan technology applied, easy to operate, and highly confidential.

Super Client

1, 4, 9,16,25,36, 64, 81-channel central management software, no user number limitation, centralized surveillance, remote record and playback, alarm email, etc.

System

OS

Embedded Linux OS

Control protocol

ONVIF 2.0 protocol, high interoperability

Video coding

Multi stream:720P@30fps+VGA@30fps+QVGA@30fps+720P @1fsJPEG capture

Bit Rate

CBR/VBR, output bit rate range:128~4096kbps

Processor

Hi processor built in ARM926 @Max. 440MHz and high-speed video co-processor

Video

Compression Format

H.264 baseline profile@levels:3.1/Motion-JPEG

Frame rate

30fps/24fps(720p)

Resolution

720P(1280*720), VGA(640*480), QVGA(320*240)

Picture Adjustment

Contrast, Brightness and Saturation are adjustable.

Sensor

1/3" 720p Progressive CMOS sensor

Minimum illumination

0.8Lux/F1.4(colorful model ),0.3Lux/F1.(B&W mode)

SNR

≥39dB

IR control

IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.

Electronic shutter

1/50s(1/60s)-1/100, 000s

CMOS

Supports AWB, AGC, BLC

Lens/viewing angle

3.6mm @ F1.4/56.14 degrees

Night Vision

Night vision

Dual IR-CUT Filter auto switch, 11pcs 850nmΦ5mm LED, 10m IR detection distance, 1pc photosensitive sensor.

Audio

Compression format

ADPCM/32kbps

Input

Sensitive MIC

Output

2 x 0.5W speaker

Pan/Tilt

P/T

Pan:355°,Tilt:120°

Preset Position

Supports up to 15 preset positions

Network

network interface

10Base-T/100Base-TX Ethernet interface

Network Protocol

TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,etc.

Wireless network security

WPS encryption

Online visitor

Supports10   online visitors simultaneously

IP address

Dynamic IP and static IP address

WIFI

WIFI 802.11 b/g/n

Others

housing material

engineering plastics

Application environment

Indoor

Rated Voltage

DC5±0.3V

Temperature

-10~50 °C

Power consumption

rated power:3.5W(IR opening )/maximum power:7W(P/T working )

Unit Dimension

195mm x140mm x130mm (L.W.H)

Alarm

Motion Detection

Supports motion detecting

System Requirement

System configuration

Win/XP,Vista,win7 win8  iPhone iOS4.3,The android version 2.3 or higher

Certificate

Certificate

ISO FCC CE RoHS



Standard Package List of the Home Security Wi-Fi IP Camera

1 x Home Security Wi-Fi IP Camera

2 x Wireless Keychain Remote Controller

1 x Wireless Door Magnetic Sensor

1 x P.I.R Motion Detector

1 x Adapter

1 x User Manual

Optional Parts: All of our other Sensors and Detectors.
