| Model: | FC-120 |
|---|---|
| Brand: | FC |
| Origin: | Made In China |
| Category: | Industrial Supplies / Rubber & Plastics Machine |
| Label: | EPE Foam Sheet Machi , PE foam film extrude , LDPE foam sheet |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:14 Jul, 2015 |
Product introduction:
EPE Foam Sheet is a new type of packing material also named as pearl cotton .It is an ideal substitute of traditional packing material for many advantages including dampproof, shockproof, sound insulation, heat preservation and high plasticity.As a new type packing material it is widely used in the packing of electronic product, commodity, glass, ceramic, household apparatus, spraying, furniture, hardware product and toy ect .
Main Technical Parameters:
|
Type |
FC-FPM90 |
FC-FPM 105 |
FC-FPM 120 |
FC-FPM 150 |
FC-FPM170 |
|
|
Extruder |
|
90/55 |
105/55 |
120/55 |
150/55 |
170/55 |
|
Screw rotate speed |
r/min |
5-45 |
5-45 |
5-45 |
5-45 |
5-45 |
|
Foam ratio |
|
20-40 |
20-40 |
20-40 |
20-40 |
20-40 |
|
Product width |
mm |
1000-1500 |
1000-1800 |
1000-2000 |
1000-2000 |
1000-2000 |
|
Product thickness |
mm |
0.5-3.5 |
0.5-5.0 |
0.8-8.0 |
1.0-10.0 |
2.0-15.0 |
|
Cooling mode |
|
Air-cooled, water-cooled |
||||
|
Installed capacity |
kw |
90 |
100 |
120 |
150 |
180 |
|
Dimension |
mm |
20000×2300×2200 |
23000×2300×2200 |
25000×2300×2200 |
30000×2300×2200 |
32000×2300×2200 |
|
Equipment weight |
T |
8.5 |
9 |
12 |
15 |
17 |
