GFP151U-0325B[3V2.5A]
GFP151U-A325B [3.3V2.5A]
GFP151U-0525B [5V2.5A]
GFP151U-0623B [6V2.3A]
GFP151U-0916B [9V1.6A]
GFP151U-1015B [10V1.5A]
GFP151U-1212B [12V1.25A]
GFP151U-1510B [15V1A]
|
Model Number
|
Input Range
|
Output Range
|
|
GFP151U-0325B
|
90-240V
|
3.0V
|
2.5A
|
|
GFP151U-A325B
|
3.3V
|
2.5A
|
|
GFP151U-0525B
|
5.0V
|
2.5A
|
|
GFP151U-0623B
|
6.0V
|
2.3A
|
|
GFP151U-0916B
|
9.0V
|
1.6A
|
|
GFP151U-1015B
|
10V
|
1.5A
|
|
GFP151U-1212B
|
12V
|
1.2A
|
|
GFP151U-1510B
|
15V
|
1.0A
|
DIMENTION:L*W*H=60.4*44*26.2
[Input Voltage]: AC 100-240V,50/60Hz
[Range Voltage]: AC 90--264V,47/63Hz
[Output Power]: 12W -15W
[Output Voltage]: 3V-24V
[Over Voltage Protection]: 120%min
[Over Current Protection]: 120%min
[Short Protection]: Auto Recovery
[Load Regulation]: ±5%
[Operating Temperature]: 0~40℃
[Storage Temperature]: -20~85℃
[Operating Relative Humidity]: 5~95%RH
[Withstanding Voltage]: AC 3000V(Min),5mA(Max)
[Insulation Resistance]: DC 500V 100MΩ(Min)
[Safety]: UL/cUL PSE CB FCC CCC
[Market]:Japan,USA,Canada,China,Taiwan
