GFP121T-0320 [3V2A]
GFP121T-A320 [3.3V2A]
GFP121T-0520 [5V2A]
GFP121T-0620 [6V2A]
GFP121T-0913 [9V1.3A]
GFP121T-1012 [10V1.2A]
GFP121T-1210 [12V1A]
GFP121T-1508 [15V0.8A]
|
Model Number
|
Input Range
|
Output Range
|
|
GFP121T-0320
|
90-240V
|
3.0V
|
2A
|
|
GFP121T-A320
|
3.3V
|
2A
|
|
GFP121T-0515
|
5.0V
|
1.5A
|
|
GFP121T-0520
|
5.0V
|
2A
|
|
GFP121T-0618
|
6.0V
|
1.8A
|
|
GFP121T-0620
|
6.0V
|
2A
|
|
GFP121T-7516
|
7.5V
|
1.6A
|
|
GFP121T-0913
|
9.0V
|
1.3A
|
|
GFP121T-1012
|
10V
|
1.2A
|
|
GFP121T-1210
|
12V
|
1A
|
|
GFP121T-1508
|
15V
|
0.8A
|
DIMENTION:L*W*H=60.4*44*26
[Input Voltage]: AC 100-240V,50/60Hz
[Range Voltage]: AC 90--264V,47/63Hz
[Output Power]: 12W-15W
[Output Voltage]: 3V-24V
[Over Voltage Protection]: 120%min
[Over Current Protection]: 120%min
[Short Protection]: Auto Recovery
[Load Regulation]: ±5%
[Operating Temperature]: 0~40℃
[Storage Temperature]: -20~85℃
[Operating Relative Humidity]: 5~95%RH
[Withstanding Voltage]: AC 3000V(Min),5mA(Max)
[Insulation Resistance]: DC 500V 100MΩ(Min)
[Safety]: GS/TUV CE
[Market]:Europe
