Product Description
GYH-2003-180W high power LED street lamp
★ chip adopting international leading technology, patented packaging technology
★ energy saving, green, environmental protection, service life of up to 10 years
★ high thermal conductivity aluminum radiator
★ quadratic optical non-cost technology, lighting a light for more than 90%
★ wide voltage input AC drive steady stream, which can be accessed directly replace the original lamp used
★ respiratory lighting design, to ensure that the lamp of dust \ water \ and self-cleaning
★ beautiful and flat light angle adjustable from 0 to 45 degrees, and better adapt to different lighting environments
★ According to customer demand, outriggers adjustable 0 to 20 degrees elevation, which can meet various needs of the installed pole road
★ Application: sub distributors \ Factory Road \ Park Road \ City Bypass
Technical reference operation:
Product Name: GYH-2003
Product Type: GYH-2003-180W
Product power: 180W
Input voltage: AC170-250V
Power frequency :50-60Hz
Output voltage: DC53V
Power Factor:> 0.95
Total harmonic distortion: <3%
Power Efficiency:> 88%
LED power consumption: 200W
System power: 227W
LED luminous efficiency:> 92Lm / W
Initial luminous flux LED lighting: 19800Lm
Light extraction efficiency:> 90%
Uniformity of surface pressure:> 0.6
Correlated color temperature: 4000K ~ 6500K
Color factor: Ra> 75
Light distribution curve / spot: bats wing / rectangular beam
Junction temperature: <75 degrees
Working Environment: Temperature -40 degrees to 50 degrees, relative humidity 10% ~ 95%
Protection class: IP66
Life:> 50,000 hours
Material: Aluminum
Net weight: ~ 16.8KG
Packing size 575 * 485 * 300mm
Product Image
