2-layer PE Film Co-extrusion Line

Model:	Serial
Brand:	Jingyeda brand
Origin:	Made In China
Category:	Industrial Supplies / Rubber & Plastics Machine
Label:	extruder , co extrusion extrude , color strip film mac
Price:	-
Min. Order:	-

Inquire Now Add to Basket

Member Information

Shenzhen Jing Ye Da Industry Co.,Ltd

Free MemberGuang Dong - China

Live Chat:

Last Online:24 Mar, 2020

Product Description

Applications:
Color Stripe Film Co-Extruder is basically a 2-layer PE Film Co-extrusion machine. It is mainly to produce LDPE,HDPE and LLDPE co-extruded color stripe film. You may use 1 hopper with master batch of red color, yellow color, etc.

Features:
1.Double-layer co-extruded film is stiff and of top quality. And widely welcomed by global buyers.
2. For top shopping bag making. Much cheaper than laminates
3. 2-layer Rotational air ring with fully rotational die is demanded to insure top quality.
4. Corona treater is optional at request.
5. Optional items at request: Motor without belt, Iris hexagonal cage, Mick weight controller and fully rotational die and 2-layer air ring.

Technical Parameters:

Type	D45x2x700	D55x2x1000	D65x2x1200	D75x2x1600	D80x2x 2000	D90x2x2500
Main Motor	11 KWx2	15 kwx2	18.5 kwx2	30kw x2	37 kwx2	45kw x 2
Valid width	600 mm	900 mm	1100 mm	1500 mm	1800 mm	2300 mm
Screw	20--150 rpm	20-150 rpm	20-150 rpm	20-150 rpm	20-150 rpm	20-150 rpm
Screw & cylinder	38 CrMoALA+nitride	38 CrMoALA+nitride	38 CrMoALA+nitride	38CrMaAlA+ nitride	38 CrMoALA+ nitride	38CrMoAlA
Screw Length/Dia.	32:1	32:1	32:1	32:1	32:1	32:1
Production	70 kg/hr	90 kg/hr	120 kg/hr	160 kg/hr	200 kg/h	240 kg/h
Film thickness	0.009-0.15 mm	0.009-0.15 mm	0.009-0.15mm	0.009-0.15	0.01-0.20mm	0.01-0.20mm
Haul speed	0-50 mpm	0-50 mpm	0-50 mpm	0-50 mpm	0-50 mpm	0-50mpm
Weight	3.0 T	4.0T	4.8 T	60T	7.5T	11.0T
Dimensions	4.0 x 2.0x 3.6 mm	4.5 x 2.5 x 3.8	5.0 x 2.8 x 4.5	6.0x3.0x5.5	6.5 x 3.8 x7.5	7x4x10

Embed HTML Code:	http://player.youku.com/player.php/sid/XNzQwNTQ3NzEy/v.swf

Product Image

Img 1

Img 2

Img 3

Img 4

Img 5

Img 6

Img 7

Img 8

Img 9
