A miniature flange mounting reed sensor occupying only 3.22mm² (0.500"²) board space with a choice of normally open, normally open high voltage, normally closed or changeover contacts.
| Specifications: | A miniature flange mounting reed sensor occupying only 3.22mm² (0.500"²) board space with a choice of normally open, normally open high voltage, normally closed or changeover contacts.
|
| Advantages: | Sensor Body Material / A.B.S
Filling / Epoxy
Max Contact Rating / 10W
Max Switching Voltage / 100 VDC
Max Switching Current / 0.5A
Min Breakdown Voltage / 220 VDC
Max Carry Current / 1.0A
Max Contact Resistance / 100 mΩ
Min Insulation Resistance / 108 Ω
Release Time / 0.1 ms Max
Operate Time / 0.4 ms Max |
click for larger image
Img 1
Img 2
Img 3
Img 4
Img 5
