| Model: | SH73032D |
|---|---|
| Brand: | SHOOT |
| Origin: | Made In China |
| Category: | Industrial Supplies / Forest Machinery |
| Label: | boring machine , drilling machine , double head boring |
| Price: |
-
|
| Min. Order: | 1 pic |
| Live Chat: | Last Online:09 Apr, 2024 |
| Customized Vertical and Horizontal Drilling Machine | |
| Feature | |
| 1.Vertical drill and horizontal drill can work simultaneously and independently | |
| 2.Hinge hole can be drilled when the vertical drill is replaced | |
| Model | SH73032D |
| Spacing | 32mm |
| Length | 810mm |
| Length of guiding rule | 1125mm |
| Width | 830mm |
| Height | 1500mm |
| Table size | 725x435mm |
| The height from the table top to the ground | 790mm |
| Voltage | 380v/ 50/60hz |
| Pure copper motor power | 1.5kw x 2 |
| Air pressure | 6-8 pressure/0.6-0.8MPa |
| Air pipe diameter | 8mm |
| The maximum number of holes drilled as standard | 6 |
| Shaft number of vertical drill package | 3 |
| Spacing between each shaft of vertical drill | 32mm |
| Number of horizontal drill packages | 3 |
| Spacing between each axis of horizontal drill | 32mm |
| Standard drill bit diameter of vertical drill | 15mm x 3 |
| Horizontal drill standard bit diameter | 8mm x 3 |
| Maximum depth of vertical drill hole | 50mm |
| Maximum depth of horizontal drilling | 50mm |
| Maximum pressing height of pressing cylinder | 65mm |
| Look Machine Video,click the Youtube website: | |
| https://youtu.be/1TuTgrOszvI | |
