Information about machines:
1. 30B Pulverizer:
1.1 The diameter is 1mm, granule is about 15mesh.
1.2 Production capacity: 50-300kg/h;
1.3 Main bearing rotary speed: 3800r/min;
1.4 Material-in granule size: ≤8mm;
1.5 Motor: 5.5KW;
1.6 Overall size: 720x650x1400mm;
1.7 Material: the part outer cover which contact with material is: SS304, seat and motor is A3 steel;
2. ZS515 Screen Machine:
2.1 Motor: 0.75Kw;
2.2 Production capacity: 100-1000kg/h;
2.3 Screen Mesh: 12-200mesh;
2.4 Overall size: 710×710×1290mm;
2.5 Material: the part outer cover which contact with material is: SS304, seat and motor is A3 steel;
3. V300L or HDJ200L mixer:
3.A. V300L Mixer:
3.A.1 Overall size: 2050x800x1820mm;
3.A.2 Total volume: 300L, loading volume: 0.4-0.6, efficient volume: 120L-180L, efficient putting material weight: 120-180kg (according to water content 1 counting);
3.A.3 Material: SS304, inner and outer is polishing;
3.A.4 Motor: 1.1kw;
3.A.5 Collocation: speed reducer is Zhengjia Hengxin, electrical device is Delixi, bearing is produced by Haerbin.
3.B.1 Total volume is: 200L, efficient working volume is: 80—160L, each time putting loading is 64-130kg (the weight is counting as 0.8). All applies SS304(except the motor and bracket).
3.B.2 Overall size: 1300x1600x1500mm;
3.B.3 Inner and outer of mixing material barrel is polishing, meet GMP requirements;
3.B.4 Motor: 2.2KW;
3.B.5 Collocation: speed reducer is Zhengjia Hengxin, electrical device is Delixi, bearing is produced by Haerbin
4. DXDC15 Tea Bag Packing Machine:
Automatic Teabag packing machine model DXDC15 is newest generation machine. It has functions of filling, heat sealing, threading, labeling and overwrapping and this model extends the packing volume of teabag to suit for special requirements from medicine, health drinking and herb industry. This machine adopts sealing pads to replace the sealing rollers on old machines and the actuating system is controlled by transducer. The new system greatly improves machine’s flexibility for different packing materials and will supply best teabag package. Many kinds of packing material will get good performance on this machine such as paper/P.E, Plastic/Foil/P.E, Plastic/P.E etc.
Main Technical Data of Model DXDC15:
Output: 105±5bags/minute
Max. dosage: 15cm3
Bag dimensions: 65mm×62.5mm
Envelope dimension: 82mm×75mm
Tag dimensions: 28mm×24mm
Thread length: 210mm
Power Supply: AC380V/220V
Total Power: 2.36kW
Weight: 1210KG
Overall dimensions: 1688mm×1330mm×22050mm
Website:: www.sunhang.com; www.pharmpackage.com Email: shpm88@sunhang.com |
Packing box dimensions: 1840×1290mm×1890mm
