| Model: | FG-2.0 |
|---|---|
| Brand: | SHENNONG STERILIZER |
| Origin: | Made In China |
| Category: | Industrial Supplies / Pharmaceutic Machine |
| Label: | sterilizer , autoclave , steam sterilizer |
| Price: |
-
|
| Min. Order: | - |
| Live Chat: | Last Online:11 Nov, 2020 |
This serises adopts the sterilization principle of mixed pressure by air and steam. Through one or several double-speed air blowers with high energy, the mixed gas compellingly cycle in the middle of sterilizing products. This not only provides better heat penetrability, but slso guarantees the even distrbution of temperature. This seeres is mainly desined to sterilize products whose container and package must be dried after cooling (ex.Cheeking, labeling, packing, etc).it is suitable for all industries to sterilize liquids in PE or PP plastic bottles. PVCof compound plastic soft package, erc.
Model Overall Dimensions L*W*H(mm) Single/Double Door Chamber Size L*W*H(mm) Steam (kg/cycle) Compressed Air (m3/cycle) Cooling Water (kg/cycle) Sterilizing Car (pcs) Power (KW) Net Weight (kg) Double door FG-1.2 1910*3400*2130 1500*1300*1300 85 2 1200 2 4 2000 FG-2.5 3410*3400*2130 3000*1300*1300 120 3.5 2000 4 5.5 3500 FG-5 3850*3700*2230 3400*1600*1700 250 6 4000 4 8 6000 FG-8 5850*3700*2230 5400*1600*1700 500 9 5500 5 8 8500 FG-10 7150*3700*2300 6700*1600*1700 650 12 6500 6 10 11000 FG-12 8450*3700*2230 8000*1600*1700 850 15 7500 8 12 13000 FG-14 9850*3700*2230 9400*1600*1700 1000 18 8500 10 15 15000
Structure & Capability & Characteristics
Fine working case body and chamber
Rectangle case body with the strengthen tendon is designed and made according to the 《Steel Pressure Vessel》 standard and 《Pressure Vessel Technical Detection Regulation 》. The inside layer and all pipes are made by good quality
Patent door lock device
Cylinder-driving device is the pioneer in the same occupation in domestic market. It is easy to operate without maintain. The reliable mechanical electric interlock make ensure the safe operating.
Seal Trip
The gasket ring is made of good quality silicone rubber which can resist
Reliable stabile micro-computer automatical control
As the main system controller,touch-screen+PLC is selected worldwide well-known brand and reliable. In the matter of data managing, the real-time print or CF card store can be choosed.
Elegant decorate cover
The cover is made of wiring-drawn stainless steel, good outlook, serviceable and easy to clean.
Asepsis guarantee and equipment confirmation
The traditinal temperature time control and Fo ＆#118alue detect the sterilizing result. And the multi point temperature control can wipe out the error effect which is rised by the temperature sensor.
The GMP conformation access is fixed which can supply GMP confirmation one time freely.
The excellent pressure tracking control
The sterilizing for the plastical vessel, the temperature and pressure parameters is depending to the liquid and vessel material. The any pressure changes must be connected with the temperature correctly. The burst, distort and color changing are avoided by the PID temperature control technology, accuracy real-time pressure tracking and the rapid cooling which can get the international standard.
Rapid cooling, drying system
After sterilizing introduce the cooling water into the condensing coil group to condense the steam. Then evaporate the water through two-speed air blower make the gas convected in the chamber to rapid cooling and drying.
Main Parameters& Utilities
Design Pressure | 0.245Mpa | Heat Equilibrium | <span style="FONT-FAMI |
