1. It can produce ultra-thin or fluffy pulp cotton core type sanitary napkin, which is individual fast-easy package.
2. PLC+touching screen+frequency regulator control system. Embossment roller temperature, driving speed and soon.
3. The planetary gear change-over mechanism is used to rotate the product for 90 and air values are used to control the suction force, thereby the products may be rotated for 90 fast and surely.
4.The soft-wrapping type is applied for small package, and hot-pressing & cutting type is adopted to ensure the products artistic and smooth appearance.
5.The integral machine is driven by frequency-control motor, and transmit in the combined of the bevel gear, universal coupling and synchronous belt.
6. Without stopping machine, automatically re-feed and exchange toilet paper, non-woven fabric, P.E film; auto control material tension, exchange material and get rid of wasted products, Machine stops automatically when breakdown takes place.
7. Teeth-like crusher can take treated or untreated rolled pulp.
| Specifications: | Main technical parameters
1.Designed speed: 140m/min
2.Running speed: 350-400pcs/min
3.Product Size: Single type (product lengh can according to customers’ require)
4.Capacity: 140kw 380V, 50 HZ (Including glue Applicators)
5.Practical capacity: 100kw Breaker: 400A
6.Electricity: 3phases 4 lines Cable: 3x70mm2+1x50mm2+1x25mm2
7.The lowest air pressure: ≥0.6mpa, 1.3m3/min
8.Total weight: about 35Tons
9.Noise: <80db (A)
10.Main machine overall dimensions: (22x5x3)M (LxWxH)
11.Machine taking total space: (26x9x4)M (LxWxH)
12.Container: 2x40HQ
Optional device:
1.Perfume adding device
2.Inner core printing device
3.ADL adding device
4.Counting machine
|
| Advantages: | Main functions and features
1.It can produce ultra-thin or fluffy pulp cotton core type sanitary napkin, which is fast-easy package.
2.Main material like Non-woven, PE film, packing film, air-laid paper auto splicing, tension control, auto guider and unqualified parts will remove automatically.
3.Cutter material use 45 # steel, extend life of the cutter.
4.Higher speed crusher machine can crush treated or untreated fluff pulp.
5.Touchable Screen: Motor switch on/off, running speed, time, counting pieces, parameter setting, alarm, error display, error enquiry (functions setting appear on screen are different according to different machine type)
6.Machine with safety door
|
| Payment Details: | T/T,T/C,D/P |
| Min Order: | 1SET |
| Ship Date: | 40-100 DAYS |
| Standard Met: | CE |
