| Model: | GW-9500 |
|---|---|
| Brand: | GREWIN |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | coil winding machine , transformer , inductor |
| Price: |
US $800
/ PCS
|
| Min. Order: | 1 PCS |
| Live Chat: | Last Online:21 Jul, 2022 |
SPECIFICATION:
|
Model |
GW-9500 |
Spindle |
1 |
|
Wire diameter |
0.5-4.0 |
Spindle motor |
500W/DC |
|
Wire spacing |
0-9.999MM |
Max. speed |
1600/400RPM |
|
Spreading Motor |
Stepper motor |
Size |
950*520*900 |
|
Power supply |
AC 220V 50/60HZ |
Weight |
60 |
FEATURES:
Big Coil Automatic Winding Machines’ controller adopts microcomputer control, data setting is easy.
The wireline shaft is driven by a stepping motor with a constant current circuit, with fast wireline speed and high precision.
The position of the Big Coil Automatic Winding Machine point can be input by teaching and display the current position of the spool.
the use of copper guide wheel, wear resistance.
With foot switch device, the production operation is fast and convenient.
The winding point can be set in sections. Width, line distance and speed, etc., in order to achieve the purpose of multi-section and multi-speed.
Big Coil Automatic Winding Machine can set 999 step sequence, and can store the set value for more than one year.
The wire frame is controlled by magnetic damping tension regulator and cylinder to achieve the purpose of precise tension adjustment.
The tail seat adopts cylinder type control, the operation is more convenient and quick.
ADVANTAGES:
Big Coil Automatic Winding Machine can accurately adjust the automatic winding machine winding speed, tie number, time, deb ing is also convenient.
The line is compact and neat, the line diameter deformation is not affected.
According to the input of different programs, can be wound around a variety of different windings in the same machine, a person's labor force can complete the work of more than a dozen people in the past, productivity and efficiency improved.
And automatic winding machine can work continuously, the efficiency is greatly improved, and reduce the cost of enterprises.
Automatic winding machine to save power.
Workshop personnel can complete the operation after simple training, more humanized.
APPLICATION:
Automatic Coil winding Machines are used for winding the small EI transformers, signal transformers, inductors, filter choke coil, relays, current contactors, valve coils, solenoid coils, telecom bobbin transformers. It can complete the coils without any one operator in fully automatically.
