TK-AM
850nm Intensity Modulator
TK-AM series 850nm lithium niobate electro-optic intensity modulator adopts advanced proton exchange technology. It has the characteristics of low insertion loss, high modulation bandwidth, low half-wave voltage and so on,and mainly used in space optical communication system, cesium atomic time reference, pulse generator, quantum optics and other fields.
Features:
Low insertion loss
High Bandwidth
Low half-wave voltage
High stability
Applications:
Space optical communication system
Cesium atomic time reference
Pulse generator
Quantum optics
Performance parameter
Limit Conditions
|
Parameter |
Symbol |
Unit |
Min |
Typ |
Max |
|
Input optical power |
Pin,Max |
dBm |
|
|
20 |
|
Input RF power |
|
dBm |
|
|
28 |
|
Bias voltage |
Vbias |
V |
-20 |
|
20 |
|
Operating temperature |
Top |
ºC |
-10 |
|
60 |
|
Storage temperature |
Tst |
ºC |
-40 |
|
85 |
|
Humidity |
RH |
% |
5 |
|
90 |
