| Model: | AESGW22-8 |
|---|---|
| Brand: | GREWIN |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | coil winding mahcine , winding machine , transformer |
| Price: |
US $3000
/ PCS
|
| Min. Order: | 1 PCS |
| Live Chat: | Last Online:21 Jul, 2022 |
Specifications：
|
Spindle number |
8 |
|
Wire size range |
0.1-0.5mm |
|
Loop diameter |
260mm |
|
Max wire distance |
9.99mm |
|
Winder width |
180mm |
|
Max speed |
0-3500 RPM |
|
Spindle motor |
Three Phase motor AC Drive |
|
Winder motor |
Stepping motor |
|
Input power |
220V 50HZ/60HZ |
|
Machine size |
1320×900×1320mm |
|
Package size |
1630×1050×1520mm |
|
N/G weight |
200kg/442kg |
Features:
There have eight pcs winding head, the winding head length and elevation can be easily adjusted.
Equipped with mobile wire frame (including eight group bobbin and eight spools ,size is 120mm × 300mm diameter ).
Install brake resistors, the position more accurately
Multi spindle coil winding machine design of 32 bit controller chip, It’ll be faster, and higher reliability.
In Chinese and English display,easy to operation,winding data retention after power failure, not to discarded products。
All the parts for multi spindle coil winding machine are imported prats,such as:Japan Bearing (NSK、NTN),Japan BANDO belt ，U.S.A GATES belt ，Taiwan Ball screw (TBI)，Taiwan Transducers and so on.
Change the winding spindle is by pneumatic .
Eight Spindle Motor Coil Winding Machine can be used for multi connected, coil automatic wire winding of multilayer type , it can winding 1-8 wire at one time.
Coil winding machine can also be pass the groove automatically .
Coil winding machine can winding 1-32 coils in the winder length range.
There are two alternate use of the square shaft rotatable about the coil diameter 25MM-180MM, high production efficiency.
For the characteristics of the machine winding ,the machine body use thick cast iron , The vibration and noise of smaller machines, it also have when wire cutting the machine will stop function, not discarded products.
Multi spindle coil winding machine can winding a variety of motor coil product, including industrial motors, air conditioner motors, washing machine motors, fan motors,Fishing line spool product.
Advantages:
There have eight pcs winding head, the winding head length and elevation can be easily adjusted.
Equipped with mobile wire frame (including eight group bobbin and eight spools ,size is 120mm × 300mm diameter ).
With two mold spindle :dimensions 16 × 16 × 630mm
Supply frame size is 800 × 800 × 780mm.
Install brake resistors, the position more accurately
