L3-VET Portable Full Digital Color Doppler

• Warranty: 2 years
• After-sale Service: Online technical support
• Shelf Life: 2 years
• Quality Certification: CE
• Instrument classification: Class II
• Safety standard: GB15979-2002
• Type: Doppler Ultrasound Equipment
• Delivery: 3(THREE) working days after receiving the payment.
• MOQ: 1 set

Main Spec:

• Display: 15inch high resolution LED
• Battery: Built-in Lithium Battery, 2.5hours
• Storage: 120 G
• Detecting Depth: 300mm
• Scanning: Electronic linear array, electronic convex array
• Power requirements: AC (AC) 220V ± 22V 50Hz ± 1Hz
• Input power: 350VA

Standard configuration

• Main unit,
• 3.5MHz convex probe
• 15″ LCD monitor, USB port
• one probe connector
• DICOM3.0

Optional configuration

• 7.5Mhz (2.0-10.0Mhz) linear probe
• 7.0MHz (2.0-10.0Mhz) trans-vaginal probe
• 2.0MHz (2.0-10.0Mhz) Micro-convex probe
• Thermal printer
• laser printer
• Trolley

Specification for the color doppler ultrasound scanner:

• With high precision digital beam forming and Doppler ultrasonic imaging technology, Pro incorporated the latest image processing technologies such as THI, speckle reduction, multi-beam parallel processing and efficient full- -digital image management system is easy to acquire better image. Special measurement software packages, flexible configuration and ergonomical design greatly increase operators clinical diagnosis accuracy and analysis efficiency.

Displaying mode:

• B, 2B, 4B, left & right, B|M, B|D, PW, M, B mode, part zoom, B|C|D, B|C|M, B|C, duplex, PW, CFM, CPA

Signal processing:

• Full-digital beam forming, dynamic filter, orthogonal demodulation, space-time filter, dynamic real-time receiving focusing, RDA, DRA, spectral processing, CFM processing

Image processing:

•  THI, speckle-reduction, color coder, frame averaging, micro- angle adjustment, wall filter, 256 grey scale, scanning angle/width control, composite processing of tissue and blood flow image

Packing:

• Package: Packed double cartons bound with four plastic belts externally
• Packaging size: 97*68*141cm
• Net weight: 6.5kg

Trolley

• Appearance
• Weight: 7.3kgs

Application:

• Abdomen / Obstetrics（OB）/ Gynecology（GYN）/ Urology / Andrology / Small Parts / Vascular / Pediatrics / Musculoskeletal, etc.

Probe Optional：

•  Convex probe
•  linear array probe
•  Veterinary micro-convex probe
•  Veterinary trans-rectal probe
